PAsmartBULK
This module offers an automatic search for bulk goods
components and the integrated component turning
station even fully automatically turns parts that are the
wrong way up.
The automatic component search alleviates and
accelerates the production of the smallest series and
prototypes considerably. The software automatically
scans with the head camera for the required compo-
nents prior to each assembly. In doing so, it even takes
into consideration the component size in case a wrong
component happens to be in the tray.
Software options
PALoose Components
The placeALL
®
range offers by standard a procedure
for manual picking of single components to create the
assembling of loose components effective and safe.
The machine isn‘t only able to pick single components
from a feeder. It features also the possibility to mark
any components before starting the assembling. This
enables the user to begin an automatic assembling
after designing.
The optional smartBULK feature recognizes auto-
matically the loose components in the container. This
quickens the assembling signicant.
PALineControl
This unit processes the division of the assembly data
on multiple machines in a line. This ensures a balanced
loading, and the whole production line is monitored.
PAPCBScan
Existing assembling and dispensing programs can be
requested by scanning the code on the PCB.
23
Software options
PATrace
This module documents which component from
which lot has been used on which circuit board and
with which order. This enables historical production
runs to be interrogated, in case of a recall enquiry.
PAStatistics
To calculate an order, all available data such as assembly
time per circuit board is documented and analyzed by
this module.
PAStorage
This module manages all SMD parts, circuit boards and
other components used in production (like heat sinks
or other standard parts) that you have in stock. The
assembled components are debited from the stock
automatically as they are used. The user is informed by
settable minimum stock levels, whether a stock item has
to be reordered.
PAStorage distinguishes between the whole warehouse
and the parts currently stored on the machine.
PABarcode
All smartFEEDERs can be set up using a wireless
barcode reader. Together with the warehousing
module you can read out the current stock. By using
the reader for a setup, it is ensured that the correct
component is set up on the correct feeder.
24
Software options
PANetState
All machine messages are transferred to a separate
PC on the network and displayed there. The user is
informed i.e. if production is nished and can initiate
further steps.
PAAcoustics
The sound module PAAcoustics early informs the user
about the end of production. Needed preparations can
be started without stopping the process.
PALevel
For assembling of MID interconnect device the module
„Z-Level“ can be integrated. This module enables the
placing of components on different levels - on higher
and deeper levels. So the module is useful for placing
components on interconnect device like for example
Embedded Components in PCBs.
PAJob
As production setups or change-over times are the
most cost-intensive activities, PAJobs analyzes which of
the predened orders takes least time to set up and
suggests it to the user for production.
PA-LEDpairing
The optional software-module PA-LEDpairing has been
developped to combinate LED to resistor. So the manual
assignement isn’t longer necessary and errors can be
avoided.
