8.2 Signal T ower Notes: (1) The signal tower lighting condition settings are made in Proper data. (2) The blue light is replaced by a green light on IEC-compatible machines. Machine Status Automatic Operation Board Load…
8. Machine Control System
8.1 Machine Control Specifications
(1) Placement Position Data Entry • Absolute data
(2) Acceleration Control (XY-table) • UHi, Hi, Mid, Low, ULow:
5-level adjustable acceleration and
deceleration settings.
(3) Controllable Axes • Cam, X, Y, Z, D1, D2, Fθ, FRθ,
Nozzle changer: 9 axes
(4) CPU • 32 bit
(5) Maximum Number of Input Sequences • 5,000 sequences/board
(6) Maximum Number of Programs • 10 (1,500 sequences/program)
in Storage
(7) Memory • Battery backup (lithium battery)
(8) Data Input • F4G system
Note: Refer to 9.2.12, “F4G System”.
(9) Data Unit • 0.01 mm on X-, Y- and Z-axes.
• θ axis units : deg. and min.
(10) Communication • RS-232C
(11) Control Panel • Numerical keypad and function keys
(12) Vision Recognition Error Correction • Board displacement correction
• Part displacement correction
– 18 – CP-642(E) Specifications
1.0
8.2 Signal Tower
Notes:
(1) The signal tower lighting condition settings are made in Proper data.
(2) The blue light is replaced by a green light on IEC-compatible machines.
Machine Status
Automatic Operation
Board Loading
Board Waiting
Command Waiting
Parts Out
M/C Stop Due To Parts Out
M/C Stop Due To Error
Statistical Warning
Operator Call During Changeover
Vision Processing Error
Ready Mode
Changeover In Process
M/C Stop Due To Production Count Up
Blue(steady)
√
√
√
√
Blue(flashing)
√
√
√
√
Yellow(steady)
√
√
Yellow(flashing)
√
√
√
Red(steady)
√
Red(flashing)
√
– 19 – CP-642(E) Specifications
1.0
8. Machine Control System
9. Options
9.1 Installation of Optional Parts and Functions
The options listed below are categorized into three groups.
Category A Factory installed (installed by Fuji prior to shipping)
Category B Site installed (installed on-site by Fuji)
Category C User installed (installed by the customer)
• Reference pin unit A or B
• Reference pins C
• Backup pins C
• Vacuum-type backup pins A or B
• Additional nozzles C
• Tape feeders C
• Handy terminal C
• Board-flow direction A
• Roller-guided conveyor A
• Tri-color signal tower A
• HELPS A
• F4G C
• Others
9.2 Further Information
9.2.1 Reference Pin Unit
(1) The CP642/CP-642(E) comes equipped with a fiducial mark camera that
reads fiducial marks to ascertain a board's position. Board-holding units for
use with reference pins are available as an option.
(2) Reference pin units can be used together with fiducial marks.
(3) The reference pin unit does not include reference pins. The reference pins
must be ordered using the customer specification form.
– 20 – CP-642(E) Specifications
