2. Environmental Specifications
2.1 Electrical Power and Air
• Voltage: 3-phase 200 VAC ±10%
• Frequency: 50/60 Hz
• Power consumption: 10 KVA
Notes:
(1) Input voltage: Selectable from 200, 210, 220, 230, 380, 400, 415, 460 and 480 V
(by selecting the transformer taps)
(2) An exclusive power source should be used for the machine in order to avoid problems from
noise, fluctuations in voltage, and high-frequency distortion.
(3) Compressed air: 0.5 MPa (5 kgf/cm
2
)
(4) Air consumption: 50 Nl/min
2.2 Environmental Conditions
• Ambient temperature : 15 to 35° C
• Ambient humidity : 30 to 80 %
• Protection Structure : Class IP22 equivalent
2.3 Machine Weight
Approximately 6000 kg (excluding the D-axis rear cover)
2.4 Machine Monitor
Either Japanese or English.
– 3 – CP-642(E) Specifications
2.0
2.5 Machine Components
• XY-table
• Board conveyor
• Feeder setting tables
• Nozzles
• Placing heads
• Vision processing system
2.6 Machine Color
Body: Beige
Trim: Reddish brown
– 4 – CP-642(E) Specifications
2.0
2. Environmental Specifications
3. Machine Specifications
3.1 Basic Specifications
• Placing Speed 0.09 sec/chip under the following conditions
> XY-table travel distance : within 14.8 mm
(within 15.3 mm including
compensation)
> D-axis movement : None
> FQ-axis rotation angle : within 20 degrees
> PQ-axis rotation angle : 90° or -90°
> Cam speed : 100%
> 180° rotation placement : 0.13 sec
• Placing Accuracy ±0.1 mm (3 sigma) in XY-direction
> Fiducial mark reference
> Rotational error is translated into an XY-coordinate.
• Placing Reliability 99.99 % (After auto recovery)
• Part Dimensions 1005 to 19 x 20 mm (20 x 20 mm for J-lead parts)
Part height: maximum 6 mm
• Package Type 8, 12, 16, 24 and 32 mm tape
Reel diameter: 180 mm, 330 mm and 380 mm
• Maximum Feeder Number 140 feeders (using 8 mm tape feeders)
• Board Loading Time 4.0 sec (XY-table travel time is not included)
• Fiducial Mark Read Time Approximately 0.5 sec/mark
> 1.2 mm mark diameter. Time needed to move between
the marks and to compensate for mark appearance and
displacement is not included.
• Nozzle Indexing Time 1 pitch rotation: 0.09 sec
2 pitch rotation: 0.15 sec
3 pitch rotation: 0.18 sec
