2-19

Operation of the Feeder

CautionWhen securing the feeder on the feeder base while pushing the

clamp lever, if the clamp lever movement is not smooth but stiff,

check whether foreign materials are jammed between the feeder

base slot and the tape feeder. Only when there is no problem,

secure the tape feeder on the feeder base.

When installing the tape feeder in the feeder base, exercise care so

that impact is not imposed on the tape feeder. A part feeding error

may occur.

2-20

SM-Series SME DB Tape Feeder User's Manual

2.4. Remove the tape feeder

Remove the tape feeder from the feeder base in the following manner:

1) Pull the clamp lever back to unfreeze the fixed tape feeder.

2) Pull the tape feeder back slowly to remove it from the feeder base.

2-21

Operation of the Feeder

2.5. Removing Waste Vinyl

In the case of the SME 8mm/W4P1 tape feeder, if the vinyl box is filled with a certain

amount of waste vinyl, the vinyl box door opens automatically and waste vinyl is

discharged. It is recommended to remove waste vinyl once the door opens. The waste

vinyl can be easily cut off using the vinyl cutter installed beside the vinyl box. After

cutting off the waste vinyl, close the door.

Figure2.19 Removing Waste Vinyl of SME 8mm/W4P1 tape feeder
