Warning Pack the machine using durable packing materials and covers to
ensure electrical protection before moving.
Operating the machine without taking proper safety measures or
in an inappropriate place may cause damage to the machine or
personal death or injury.
If the door switch is removed, since the machine will not stop
even though the door opens during operation, the user may be
injured. Do not remove the door switch. Do not attempt to remove
the door switch by making an arbitrary decision.
Do not attempt to modify the equipment without prior consent
from Hanwha Precision Machinery Co., Ltd., or repair it in a
manner not stated in this manual.
Hanwha Precision Machinery Co., Ltd.is not responsible for
problems caused by machine repairs performed in a manner not
mentioned in this manual, or any modifications carried out without
prior approval.
Be sure to turn off the power switch and then close the air-valve
before performing maintenance or repair of the machine. If these
steps are not followed, personal injury could occur.
Adjusting the sensor or taking measures against an error while
the machine in in the ‘READY’ state may cause a user to be
injured. Press the ‘EMG’ switch to release the ‘READY’ state and
perform sensor adjustment and take measures against the error
after pressing the ‘STOP’ button.
A system infected by a computer virus may make the machine
malfunction and cause damage.
We do not take responsibility for any damage to data due to an
infection by virus. Therefore, perform a virus check periodically to
prevent data from being infected.
Table of Contents
1
Table of Contents
Main Contents
Preface .................................................................................................................................. i
Caution [Before operating this machine] .......................................................................... i
About Safety .................................................................................................................... ii
Concerning Storage ....................................................................................................... iii
About Handling ............................................................................................................... vi
About Warranty .............................................................................................................viii
Chapter1.Overview ......................................................................................................... 1 - 1
1.1. Configuration of feeder .................................................................................... 1 - 1
1.1.1. SME W4P1 Tape Feeder .................................................................... 1 - 1
1.1.2. SME 8mm Tape Feeder ...................................................................... 1 - 2
1.1.3. SME 12~88mm Tape Feeder .............................................................. 1 - 3
1.2. Feeder Standard .............................................................................................. 1 - 4
1.2.1. Tape to be used/reel diameter/feed pitch/number of occupied slots accord-
ing to feeder types .............................................................................. 1 - 4
1.3. Reference for feeder’s pickup height setup ..................................................... 1 - 5
1.4. Probe Pin Components .................................................................................... 1 - 7
Chapter2.Operation of the Feeder ............................................................................... 2 - 1
2.1. Installing the SME 8mm/W4P1 Tape Feeder ................................................... 2 - 1
2.1.1. Opening Tape Guide ........................................................................... 2 - 1
2.1.2. Fixing the Tape Reel ........................................................................... 2 - 2
2.1.3. Installing the component tape and Exit of the carrier tape .................. 2 - 3
2.1.4. Locking ................................................................................................ 2 - 6
2.1.5. Fixing the Vinyl Tape .......................................................................... 2 - 7
2.1.6. Setting the Pickup Point ...................................................................... 2 - 8
2.2. Installing the SME 12~88mm Feeder Tape ..................................................... 2 - 9
2.2.1. Opening Tape Guide ........................................................................... 2 - 9
2.2.2. Fixing the Tape Reel ......................................................................... 2 - 10
2.2.3. Installing the component tape and Exit of the carrier tape ................ 2 - 11
2.2.4. Locking .............................................................................................. 2 - 13
2.2.5. Fixing the Vinyl Tape ........................................................................ 2 - 15
2.2.6. Part pick-up point .............................................................................. 2 - 16
2.3. Feeder Installation ......................................................................................... 2 - 17
2.3.1. Cautions before installing the feeder ................................................ 2 - 17
2.3.2. Feeder installation procedure ........................................................... 2 - 18
2.4. Remove the tape feeder ................................................................................ 2 - 20
2.5. Removing Waste Vinyl ................................................................................... 2 - 21
2.6. How to Operate the SME Tape Feeder Switch .............................................. 2 - 22
