SIPLACE Recovery Installation on Celsius W380 10/2011 Edition
Figure 4-14: Workaround to skip IP configuration
► Instead of defining the IP address in this step, select Obtain IP automatically and click the Next
button.
NOTICE
XP Setup - empty Gateway not accepted
Since the Windows XP Setup doesn’t accept empty gateways, we use DHCP in this
configuration step. Instead, the SIPLACE customized network configuration window will
allow you to configure the IP correctly later.
26
SIPLACE Recovery Installation on Celsius W380 10/2011 Edition
Figure 4-15: Register screen
► Since we don’t have an Internet connection, we select No, not at this time and click the Next
button.
Figure 4-16: Account specification
► Enter the SIPLACEAdmin account.
► Click the Next button to continue.
27
SIPLACE Recovery Installation on Celsius W380 10/2011 Edition
CAUTION
Account with empty Password created
Since Windows XP Setup doesn’t allow setting a password for the given account(s), you
have to set it manually after installation! This is described in the documentation
“Required Steps before using Support Media”, item no. 00197185-xx.
Figure 4-17: Finish dialog
► Click Finish to finalize Windows Setup.
Windows will continue with preparation and reboot.
28
