Installing Primergy TX300S6 with Windows Server 2008R2 SP 1 07/2011 Edition
The deployment process selection screen appears.
Figure 3-7: Deployment Process Selection screen
► Ensure that the radio button besides Typical is selected and click the Next button at the bottom
of the screen.
The Configure your Unattended Operating System Installation screen appears.
Figure 3-8: Unattended Operating System Installation Configuration screen with Windows Server 2008 R2 SP 1 selected
14
Installing Primergy TX300S6 with Windows Server 2008R2 SP 1 07/2011 Edition
► In each of the dropdown boxes, select Windows, MS Windows Server 2008 R2, Windows
Server 2008 R2 Standard, Service Pack 1 as displayed in the figure above.
► Click the Next button at the bottom of the screen.
The Configuration of Disks and RAID Controllers screen appears.
Figure 3-9: Configuration of Disks and RAID Controllers screen with default options
► Modify the default settings as displayed in the following figure.
Figure 3-10: Configuration of Disks and RAID Controllers screen with custom options
15
Installing Primergy TX300S6 with Windows Server 2008R2 SP 1 07/2011 Edition
► For RAID level, select "5".
NOTICE
Select/change RAID options carefully
In this manual, RAID level 5 is used for a good compromise between performance and
data security. RAID 5 requires three hard disks at least. In most cases, changing the
RAID level afterwards causes existing data on the involved disks to get lost. So, you
should ensure to select the proper RAID level first before setting up the computer with
important data. For more information on RAID levels, please consult the manual for your
RAID controller or search in internet for RAID documentation.
► For Boot Partition Size, select "manual" and enter the value "150000" MB to reserve about 150
GB for the boot partition (the Windows "C:" drive).
NOTICE
Whole disk with single partition
If you leave the default settings for boot partition size, a single partition containing the
whole disk will be created. After that, you will have to use a partition manager tool if you
want to split the system into more partitions.
► Click the Next button at the bottom of the screen to continue.
The next configuration screen appears.
Figure 3-11: Settings screen with additional options
► Enter a name for the user and organization.
This information will only be used for registration information – no account will be generated.
► Enter the name for the computer as required.
