Installing Primergy TX300S6 with Wind ows Server 2 008R2 SP 1 07/2011 Edition Figure 4-18: New Simple Volume Wi zard – Completed ► Click the Finish button to complete the task. Forma tting may take a couple of seconds. 4…
Installing Primergy TX300S6 with Windows Server 2008R2 SP 1 07/2011 Edition
Figure 4-16: New Simple Volume Wizard – Assign Drive Letter or Path
► Ensure that drive D is selected in the dropdown menu and click the Next > button.
Figure 4-17: New Simple Volume Wizard – Format Partition
► Select the radio button besides Format this volume with the following settings:.
► Select NTFS besides File system.
► Leave the default allocation unit size and enter a name for the new volume, e.g. “Data”.
► Select the Perform a quick format checkbox and click the Next > button.
35
Installing Primergy TX300S6 with Windows Server 2008R2 SP 1 07/2011 Edition
Figure 4-18: New Simple Volume Wizard – Completed
► Click the Finish button to complete the task. Formatting may take a couple of seconds.
4.4 Removing default gateway
As mentioned before, you have to remove the dummy default gateway that was entered during the
Installation Manager guided setup.
Figure 4-19: Opening Network Settings
► Click on Start.
► Right-click on Network and select Properties.
The Network and Sharing Center opens. and Sharing Center opens.
36
Installing Primergy TX300S6 with Windows Server 2008R2 SP 1 07/2011 Edition
Figure 4-20: Network Sharing Center – clicking change adapter settings
► Click on Change adapter settings on the left side.
Figure 4-21: Selecting Properties of connected Network Card
► Right-click on the network card that is connected (Status is not Network cable unplugged)
► Select Properties.
NOTICE
Network Card identification
This procedure only works if you have disconnected all other network cables except the
SIPLACE connection, as mentioned in the first chapter.
