POWER SUPPLY M37 OVERVIEW Chapter Issue 14, Nov 18 Technical Reference Manual 5.1 CHAPTER 5 POWER SUPP L Y M37 OVER VIEW Figure 5-1 T ype 1 Covers Item Descriptio n Item Description 1 Front Cover Interlock 5 T wo Button …
MACHINE OVERVIEW
ELECTRICAL SCHEMATIC
4.20 Technical Reference Manual Chapter Issue 11, Jan 17
POWER SUPPLY M37
OVERVIEW
Chapter Issue 14, Nov 18 Technical Reference Manual 5.1
CHAPTER 5 POWER SUPPLY M37
OVERVIEW
Figure 5-1 Type 1 Covers
Item Description Item Description
1 Front Cover Interlock 5 Two Button Control
2 Mains Isolator Switch 6 Light Button
3 M37 Power Supply Enclosure 7 System Button
4 E Stop Button
A
7
View on Arrow A
5
6
4
3
2
1
5
POWER SUPPLY M37
OVERVIEW
5.2 Technical Reference Manual Chapter Issue 14, Nov 18
Figure 5-2 Type 2 Covers
Item Description Item Description
1 Sliding Front Cover Interlock 5 E Stop Button
2 System Button 6 M37 Power Supply Enclosure
3 Two Button Control 7 Rear Cover Interlock
4 Mains Isolator Switch
7
6
5
4
3
3
2
1
