SAFETY FEATURES HIGH VOLTAGE PROTECTION 2.20 Technical Reference Manual Chapter Issue 15, Nov 18 Earth Studs and Labels on the Print Carriage 1 Earth Studs and Labels Earth Studs and La bels on the V acuum Pump 1 Earth…
SAFETY FEATURES
HIGH VOLTAGE PROTECTION
Chapter Issue 15, Nov 18 Technical Reference Manual 2.19
Mains Isolator (cover removed) Showing Earth Loom Arrangement
1 Earth Lead to Chassis M5 Stud and TB3
2 Earth Label
3 Earth Lead to Chassis M6 Stud (Protective Earth)
SAFETY FEATURES
HIGH VOLTAGE PROTECTION
2.20 Technical Reference Manual Chapter Issue 15, Nov 18
Earth Studs and Labels on the Print Carriage
1 Earth Studs and Labels
Earth Studs and Labels on the Vacuum Pump
1 Earth Studs and Labels
SAFETY FEATURES
HIGH VOLTAGE PROTECTION
Chapter Issue 15, Nov 18 Technical Reference Manual 2.21
Typical Module Earth Stud and Label
1 Earth Studs and Labels (PC/M27/M36/M37/M39)
