POWER SUPPLY M37 OVERVIEW Chapter Issue 14, Nov 18 Technical Reference Manual 5.3 Figure 5-3 T ype 3 Covers Item Descriptio n Item Description 1 Front Printhea d Cover Inte rlock 4 Mains Isolator Switch 2 T wo Button Con…
POWER SUPPLY M37
OVERVIEW
5.2 Technical Reference Manual Chapter Issue 14, Nov 18
Figure 5-2 Type 2 Covers
Item Description Item Description
1 Sliding Front Cover Interlock 5 E Stop Button
2 System Button 6 M37 Power Supply Enclosure
3 Two Button Control 7 Rear Cover Interlock
4 Mains Isolator Switch
7
6
5
4
3
3
2
1
POWER SUPPLY M37
OVERVIEW
Chapter Issue 14, Nov 18 Technical Reference Manual 5.3
Figure 5-3 Type 3 Covers
Item Description Item Description
1 Front Printhead Cover Interlock 4 Mains Isolator Switch
2 Two Button Control 5 E Stop Button
3 System Button 6 M37 Power Supply Enclosure
2
6
5
4
3
2
1
POWER SUPPLY M37
OVERVIEW
5.4 Technical Reference Manual Chapter Issue 14, Nov 18
Figure 5-4 Type 4 Covers
Item Description Item Description
1 Front Printhead Cover Interlock 4 M37 Power Supply Enclosure
2 System Button 5 Mains Isolator Switch
3 Two Button Control 6 E Stop Button
