- - 106.EREPLACING OVERALLCHAN GERTRUCKCO MPONENTS (2) 3 0 4 7 4 7 4 8 5 3 1 7 1 8 1 9 1 6 2 3 3 2 2 9 3 0 2 7 2 8 2 6 2 2 2 1 2 1 2 2 2 2 2 1 3 4 1 1 8 2 5 4 3 2 4 2 0 4 3 4 4 4 4 2 1 4 2 4 1 4 0 4 2 1 2 1 0 1 5 …

100%1 / 284
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 401-14162 EBANKASSY 1
2 401-10281 EBANKSUBASSY (1)
3 401-28160 E_BANK_BASE (1)
4 E2602-721-000 BANKLOCATEBUSHA (2)
5 E2609-721-000 BANKLOCATEPINA (1)
6 E2610-721-000 BANKLOCATEPINB (1)
7 NM-6080003-SC NUTM8 (2)
8 WS-0820002-KN SPRINGWASHERM8 (2)
9 WP-0841601-SC WASHER8.4X17.4X1.6 (2)
10 401-28166 MARKSTAND (1)
11 E2505-729-0A0 MARKASM. (1)
12 E2505-729-000 MARKBASE (1)
13 E2601-725-000 MARK (1)
14 SL-6041292-TN SCREW (2)
15 SL-6052092-TN SCREW (2)
16 401-03746 FIXINGPLATE (4)
17 SM-3040652-TN SCREWM4L=6 (12)
18 401-03747 FIXINGBLOCK (4)
19 SM-3041052-TN SCREWM4L=10 (12)
20 400-84713 EBANKSHIM0.02 (8)
21 400-84714 EBANKSHIM0.03 (8)
22 400-84715 EBANKSHIM0.05 (8)
23 400-84699 EBANKSHIM0.10 (12)
24 SM-8040612-TP SCREWM4L=6 (20)
25 SM-8030602-TP SCREWM3X0.5L=6 (12)
26 SM-8041852-TP SCREWM4L=18 (8)
27 SM-6040802-TN SCREWM4X0.7L=8 (16)
28 E3074-729-000 BEARINGSHIMD (2)
29 401-03748 RAILGUIDE9 (3)
30 401-03749 RAILGUIDE10 (1)
31 SM-6040802-TN SCREW (16)
32 400-85590 GUIDE_PLATE (41)
33 SM-3030552-TN SCREWM3L=5 (82)
34 SM-1030552-TN PLATESCREWM3L=5 (41)
35 401-28162 LOCKSHAFT (2)
36 HX-0029400-00 FIXEDBASE (8)
37 SL-4030881-SC SCREWM3L=8 (8)
38 401-38827 E_BANK_BASE_COVER (1)
39 SM-0040601-SC SCREWM4X0.7L=6 (8)
40 EA-9500B02-00 CABLEBAND150 (10)
41 400-93577 FDCBRACKETASSY (1)
42 400-93591 FDCBRACKETSTAYR (1)
43 SL-6061292-TN SCREW (4)
44 401-28140 FDCBRACKET (1)
45 SL-6051092-TN BOLT (4)
46 400-93594 ETFPOSITIONLABEL(40) (1)
47 400-92647 EFIFCBL1-5ASM (1)
48 400-92648 EFIFCBL6-10ASM (1)
49 400-92649 EFIFCBL11-15ASM (1)
50 400-92650 EFIFCBL16-20ASM (1)
51 400-92651 EFIFCBL21-25ASM (1)
52 400-92652 EFIFCBL26-30ASM (1)
53 400-92653 EFIFCBL31-35ASM (1)
54 400-92654 EFIFCBL36-40ASM (1)
55 HK-0791900-00 CONNECTOR (80)
56 400-93590 FDCBRACKETSTAYL (1)
57 HX-0022300-0A BUSHING (0.14)
58 400-93578 BANKPCBBOXASSY (1)
59 HX-0035400-0E BOARDPARTS (4)
60 SL-4030691-SC SCREWM3L=6 (6)
61 401-28042 BANKPCBBASE (1)
62 HX-0067100-0A GROMMET (0.36)
63 401-87551 ELECBANK10PCBASMV2 (1)
64 EA-9500B02-00 CABLEBAND150 (30)
65 HX-0029400-00 FIXEDBASE (6)
66 SL-4030691-SC SCREWM3L=6 (7)
67 400-93593 BANKPCBCOVER (1)
68 SL-6030892-TN SCREW (4)
69 EA-9500B01-00 CABLEBAND (30)
70 HX-0067100-00 GROMMET (0.21)
71 SL-6051092-TN BOLT (4)
72 401-07154 CLOSELABEL (1)
73 SL-6040892-TN BOLT 4
74 400-01734 SCREW 4
75 400-93582 FINGERGUARDBR 1
76 E2732-721-000 BANKGUIDEROLLER 4
- -
106.EREPLACINGOVERALLCHANGERTRUCKCOMPONENTS(2)
3 0
4 7
4 7
4 8
5 3
1 7
1 8
1 9
1 6
2 3
3 2
2 9
3 0
2 7
2 8
2 6
2 2
2 1
2 1
2 2
2 2
2 1
3
4
1 1
8
2 5
4 3
2 4
2 0
4 3
4 4
4 4
2 1
4 2
4 1
4 0
4 2
1 2
1 0
1 5
1 5
1 4
3 9
4 5
4 9
5 0
4 5
4 6
2 9
1 0
1 2
8
3 5
3 2
3 4
5 1
3 7
3 6
3 6
9
7
1 3
6
3 3
3 8
3 4
3 1
3 7
3 1
3 8
3 3
3 5
1 2
6 2
6 3
6 2
6 3
6 3
6 3
6 2
6 2
6 0
6 1
5 9
5 9
7 1
7 3
6 9
6 7
6 9
6 7
5 7
5 5
5 6
6 4
6 6
5 8
5 4
7 2
7 2
7 2
7 2
6 8
6 8
7 1
7 0
7 0
7 0
7 0
7 0
6 9
6 7
6 9
6 7
6 9
6 7
6 9
6 7
6 9
6 7
6 9
6 7
7 0
6 5
7 0
7 0
7 1
7 2
7 2
7 4
6 5
3
4
1 1
2 4
5
7 7
7 6
7 8
7 5
A
A
5 2
B
B
2 2
2 5
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 401-12818 TROLLEYASM 1
2
#02
401-20913 TROLLEY_ASM_950 1
3 WP-0621036-SP WASHER (4)
4 SM-3061052-TN SCREW (4)
5 400-94881 TROLLEY_SHAFT_L70 (1)
6 400-94837 TROLLEYUPPER (1)
7 401-10302 TROLLEYBOTTOM (1)
8 400-01730 SCALEMARKSSEAL (2)
9 SM-6125052-TR SCREWM12L=150 (2)
10 WP-1052001-SC WASHER10.5X21X2 (4)
11 400-89239 ETROLLEYPLATE (4)
12 SL-6102042-TN SCREW (4)
13 401-47459 TROLLEYSTOPPERBLOCKR (1)
14 401-47458 TROLLEYSTOPPERBLOCKL (1)
15 SL-6082092-TN BOLT (6)
16 NM-6060001-SC NUTM6X1TYPE1 (4)
17 400-94859 CASTER107N (4)
18 SL-6082092-TN BOLT (16)
19 SL-6061492-TN BOLT (4)
20 E2703-721-000 TROLLEYSHAFT (1)
21 SB-8160005-C0 BEARING (4)
22 SM-6040602-TN BOLT (16)
23 E2711-721-000 TROLLEYSTOPPER (2)
24 400-01748 TROLLEYSUBGUIDE (2)
25 SL-6062592-TN SCREW (2)
26 SL-6041292-TN SCREW (1)
27 400-23476 FGGUMSHEET (1)
28 WP-0430801-SC WASHERM4 (1)
29 SL-6083092-TN SCREW (6)
30 400-94928 TROLLEYHANDLEASM (2)
31 SL-6030642-TN SCREWM3L=6 (1)
32 SL-6040642-TN BOLT (1)
33 E2641-729-000 HANDLECLIP (1)
34 400-94854 HANDLESHAFTET (1)
35 400-21920 TROLLEYHANDLE (1)
36 PS-0400122-KP SPRINGPIN (2)
37 PS-0600182-KP SPRINGPIN (1)
38 E2635-729-000 HANDLESLIDER (1)
39 401-12820 TROLLEYTAPEGUIDEASM (1)
40 401-27990 BANK_PLATE_R (1)
41 401-27989 BANK_PLATE_L (1)
42 401-28047 LINEAR_SHAFT (2)
43 SM-8060552-TP SCREWM6L=5 (4)
44 400-98942 SUPPORTSHAFT (2)
45 SL-6061092-TN SCREW (4)
46 401-10311 TAPEGUIDEBRR (1)
47 SM-3040652-TN SCREWM4L=6 (4)
48 401-10312 TAPEGUIDESUPPORT (1)
49 SM-3040652-TN SCREWM4L=6 (4)
50 400-94372 TAPEGUIDEBRC (1)
51 401-19292 ETF_POSITION_LABEL(40)_2 (1)
52 401-10310 TAPEGUIDEBRL (1)
53 E4981-700-000 LABEL 1
54 401-10289 TRASHBOX 1
55 SM-3040652-TN SCREWM4L=6 16
56 400-94860 THCASTER 4
57 401-14554 TAPEHOLDERASM 1
58 400-84676 SEPARATIONPLATE (20)
59 401-10291 REELFIXINGBAR40 (2)
60 401-10286 TRASHBOXFRAMEL (1)
61 401-10287 TRASHBOXFRAMER (1)
62 401-10290 TAPEHOLDERFOOT (4)
63 SL-4040891-SC SCREWM4X8 (16)
64 SM-1031001-SC SCREWM3X0.5L=10 (20)
65 401-10285 TAPEHOLDERPL (2)
66 E1612-706-C00 REELSH (20)
67 SM-0030601-SC SCREWM3X0.5L=6 (8)
68 400-94863 TAPESUPPORT (2)
69 400-84674 REELSUPPORTANGLE (8)
70 SL-4030691-SC SCREWM3L=6 (16)
71 400-94862 TAPEHOLDERBR1 (3)
72 SL-4040891-SC SCREWM4L=8 (12)
73 400-94864 TAPEHOLDERHANDLE (1)
74 SL-6051092-TN BOLT (2)
75
#01
400-94513 TRASHBOXL 1
76 400-25327 CORNERPIECEB1 (2)
77 400-94959 TRASH_BOX_L_A (1)
78 400-25326 CORNERPIECEA1 (2)
