- - 111.M/EREPL ACINGOVERALL CHANGERTRUC KCOMPONENT S(1) 2 4 2 3 2 5 2 1 2 2 3 1 5 2 5 1 4 1 4 4 5 5 5 5 6 6 7 7 8 1 1 1 6 1 7 1 6 1 7 1 8 1 8 1 9 2 0 2 2 2 0 2 9 3 0 3 1 3 4 3 5 3 6 3 8 4 1 6 6 6 7 6 1 5 7 5 6 …

100%1 / 284
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 400-94895 TROLLEY_SAFTY_COVER 1
2 401-38847 TROLLEY_SAFTY_COVER_R_B (1)
3 400-99020 TROLLEY_SAFTY_COVER_L (1)
4 400-94724 TOROLLEY_SHAFT_40 (2)
5 SL-6051092-TN BOLT (2)
6 400-94723 TOROLLEY_COV_BR (2)
7 SL-6061092-TN SCREW (4)
8 SM-3040652-TN SCREWM4L=6 (2)
9 CM-3002000-03 ATTENTIONLABEL (2)
10 400-94896 TOROLLEY_TAPE_GUIDE_ASM 1
11 400-94527 TAPE_GUIDE_A (1)
12 400-98911 TAPE_GUIDE_B (1)
13 SL-4030891-SC SCREWM3X8 (2)
14 SL-4040891-SC SCREWM4L=8 (2)
15 400-94529 TAPE_GUIDE_INNER (1)
16 400-94530 GUIDE_SPACER (2)
17 400-98072 SLIDE_WASHER (4)
18 WP-0451016-SP WASHER4.5X20X1 (2)
19 NM-6040001-SC NUTM4X0.7TYPE1 (2)
20 400-94926 SPRING_5.99N (2)
21 400-94879 BURASH (1)
22 WP-0451016-SP WASHER4.5X20X1 (4)
23 SL-6040642-TN BOLT (4)
24 400-93982 BASE_GUIDE_BR_A (1)
25 400-93983 BASE_GUIDE_BR_B (1)
26 400-94965 BASE_GUIDE_BR_C (2)
27 SL-6061292-TN SCREW (18)
28 400-98973 PLATE (12)
29 400-94538 SPACER (24)
30 SL-6030892-TN SCREWM3L=8 (24)
31 WP-0431005-SP PLAINWASHER (24)
32 400-94891 SPRING_0.69N (12)
33 HX-0009600-00 EDGEBUSHING (0.8)
34 400-93579 TAPE_GUIDE_BR 1
35 400-93580 TAPE_GUIDE_SD 6
36 SM-1030601-SC SCREWM3L=6 6
37 HX-0029400-00 FIXEDBASE 3
38 SM-4040601-SC SCREWM4X0.7L=6 3
39 EA-9500B02-00 CABLEBAND150 3
40
#01
400-94878 TRASHBOXHOLDERASM 1
41 400-94848 TRASH_BOX_FLAME
(1)
42 SL-6040892-TN BOLT (4)
43 400-94851 SUB_CASTER_BR (2)
44 SM-3040652-TN SCREWM4L=6 (4)
45 400-94860 TH_CASTER (2)
46 SM-3040652-TN SCREWM4L=6 (8)
47 400-94861 SLIDE_BOLT 2
48 SL-4030691-SC SCREWM3L=6 8
49 400-94855 LOCK_BR 2
50 SL-4040891-SC SCREWM4L=8 4
51 400-94856 TH_LOCK_BR 2
52 SM-3030552-TN SCREWM3L=5 4
53 WP-0320501-SC WASHERM3 4
54
#01
400-94857 CUTTER_PUSHER 1
55
#01
SL-6040892-TN BOLT 2
56
#02
401-26513 TROLLEY_TAPE_GUIDE_ASM_REV_B 1
57 401-38828 TAPE_GUIDE_A (1)
58 WP-0641601-SC WASHER (4)
59 401-38831 TAPE_GUIDE_FIX_BR_L_A (1)
60 401-38832 TAPE_GUIDE_FIX_BR_L_B (1)
61 401-38833 TAPE_GUIDE_FIX_BR_R (1)
62 SL-6061292-TN SCREW (2)
63 SL-6040892-TN BOLT (2)
64 SM-6061202-TN BOLT (2)
65 401-26049 TAPE_GUIDE_B_ASM_TROLLEY (1)
66 401-38836 TAPE_GUIDE_B (1)
67 401-26047 SHUTER_ASM (1)
68 401-38829 SHUTTER_PLATE (1)
69 401-38835 MAGNET_RUBBER_SHEET (2)
70 401-38837 UPDC_HANDLE_BR (1)
71 SM-3030552-TN SCREWM3L=5 (4)
72 SL-6030692-TN SCREWM3L=6 (2)
73 401-38507 WSHER_TM-147-1 (2)
74 401-26048 SLIDE_GUIDE_ASM_TROLLEY (1)
75 401-38830 SLIDE_GUIDE (1)
76 401-38838 SHUTTER_FILM (1)
77 E2732-721-000 BANKGUIDEROLLER (2)
78 WP-0641601-SC WASHER (2)
79 WS-0610002-KN SPRINGWASHER6.1X12.2X1.5 (2)
80 NM-6060001-SC NUTM6 (2)
81 401-50864 GUIDE_SPACER_55 (2)
82 400-98072 SLIDE_WASHER (4)
83 WP-0451016-SP WASHER4.5X20X1 (2)
84 400-56921 SPRINGSTUD (2)
85 WP-0430801-SC WASHERM4 (2)
86 WS-0410002-KN SPRINGWASHERM4 (2)
87 NM-6040001-SC NUTM4X0.7TYPE1 (2)
88 401-11184 SLIDE_GUIDE_SP (2)
89 400-93982 BASE_GUIDE_BR_A (1)
90 400-93983 BASE_GUIDE_BR_B (1)
91 401-50866 BRG_SUPPORT (2)
92 E2732-721-000 BANKGUIDEROLLER (2)
93 WP-0641601-SC WASHER (2)
94 WS-0610002-KN SPRINGWASHER6.1X12.2X1.5 (2)
95 NM-6060001-SC NUTM6 (2)
96 401-50865 GUIDE_SPACER_135 (2)
97 SL-6061492-TN BOLT (4)
98 SL-6062592-TN SCREW (2)
- -
111.M/EREPLACINGOVERALLCHANGERTRUCKCOMPONENTS(1)
2 4
2 3
2 5
2 1
2 2
3
1 5
2 5
1 4
1 4
4
5
5
5
5
6
6
7
7
8
1 1
1 6
1 7
1 6
1 7
1 8
1 8
1 9
2 0
2
2
2 0
2 9 3 0
3 1
3 4
3 5
3 6
3 8
4 1
6 6
6 7
6 1
5 7
5 6
6 8
5 4
7 2
7 3
5 9
6 0
7 4
7 5
7 6
6 3
4 7
2 8
4 6
4 6
4 6
4 6
6 2
6 2
5 3
5 3
6 9
6 9
A
A
3 7 3 2 3 3
1
2 6
2 6
4 9
4 9
4 8
4 8
6 4
6 4
6 5
6 5
5 0
5 1
5 2
5 5
5 8
7 1
7 0
9
9
8
9
9
6
6
2 7
1 0
1 3
1 2
1 0
1 1
1 3
1 2
1 9
1 5
B
B
C
2 7
C
3 9
3 9
4 3
4 0
4 2
4 5
3 9
4 4
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 401-14145 DRIVECYLINDERLIFTUNIT 1
2 PC-0152030-00 SPEEDCONTROLLER (4)
3 400-93844 DCGUIDEBLOCKL (1)
4 400-93845 DCGUIDEBLOCKR (1)
5 SB-7100002-00 SLIDEBEARING (4)
6 RC-1900002-KP CRING (4)
7 401-10300 DCGUIDESHAFT (2)
8 401-10301 SHAFTCLAMPBR (2)
9 SL-6040892-TN SCREWM4L=8 (8)
10 401-10294 SHAFTCLAMPBRB (2)
11 401-10293 SHAFTCLAMPBRA (2)
12 SL-6051292-TN BOLT (4)
13 SL-6040892-TN SCREWM4L=8 (4)
14 SL-6052092-TN SCREW (2)
15 SL-6051292-TN BOLT (2)
16 400-71364 DRVSYLSPT (2)
17 SL-6051492-TN BOLT (4)
18 401-10292 DRVCYLBR (2)
19 SL-6082092-TN SCREWM8L=20 (4)
20 400-94348 CYLINDERCDM2B40-200 (2)
21 400-93831 DRIVECYLINDERUNIT 1
22 400-93843 DRIVERSUPPORT (1)
23 400-00575 DRIVECYLINDERL (1)
24 400-00576 DRIVECYLINDERR (1)
25 SL-6051292-TN BOLT (2)
26 SL-6052592-TN BOLT (6)
27 SL-6083092-TN SCREWM8L=30 8
28 401-10119 BLIFFRAMER 1
29
#01
400-92513 DRIVECYLSENSORFASM 1
30
#02
400-92514 DRIVECYLSENSORRASM 1
31 400-93834 BANDBM2-040 1
32
#01
400-94333 DCCONBRFASM 1
33
#02
400-94334 DCCONBRRASM 1
34 400-94335 DCCONBR (1)
35 SM-4051001-SC SCREWM5L=10 (2)
36 SM-4861001-SC SCREWM2.6L=10 (4)
37 401-14147 BANKAIRPARTSME 1
38 PJ-3080600-03 YUNION (4)
39 PJ-3040651-03 SWIVELELBOW (6)
40 PX-0551040-00 SILENCER(PT1/8) (2)
41 BT-0600400-EC TUBEHOSE,BLUE (15)
42 SM-6040802-TN SCREWM4X0.7L=8 (4)
43 401-11307 AIROPEVALVEBR (1)
44 400-94349 AIROPEVALVE (2)
45 SL-6040892-TN SCREWM4L=8 (2)
46 400-93838 LIFTERSHAFT 4
47 401-10117 BLIFFRAMEL 1
48 SB-8200003-00 BEARING 2
49 SM-6051602-TN SCREW 8
50 PA-6307503-00 AIRCYLINDER 1
51 PC-0152030-00 SPEEDCONTROLLER 2
52 400-93854 CYLINDERSCREWM8L=125 4
53 SM-3040652-TN SCREWM4L=6 4
54 401-10296 BANKLIFTERL 1
55 401-10295 LIFCYLSHAFT 1
56 E2622-729-000 LIFTERTHRUSTCOLLAR 1
57 SM-1062052-TP SCREWM6L=20 1
58 400-93839 BANKLOCATEPINB2 1
59 NM-6080003-SC NUTM8 1
60 WS-0820002-KN SPRINGWASHERM8 1
61 SM-8060552-TP SCREWM6L=5 2
62 400-93849 SENSORPLATE 2
63 SM-8060552-TP SCREWM6L=5 2
64 SB-8200003-00 BEARING 2
65 SM-6051602-TN SCREW 8
66 PA-6307503-00 AIRCYLINDER 1
67 PC-0152030-00 SPEEDCONTROLLER 2
68 400-93854 CYLINDERSCREWM8L=125 4
69 400-92511 SWITCHD3DC-3 2
70 401-10297 BANKLIFTERR 1
71 401-10295 LIFCYLSHAFT 1
72 E2622-729-000 LIFTERTHRUSTCOLLAR 1
73 SM-1062052-TP SCREWM6L=20 1
74 400-93840 BANKLOCATEPINC2 1
75 NM-6080003-SC NUTM8 1
76 WS-0820002-KN SPRINGWASHERM8 1
