Component Feeding

Matrix Tray Changer

Innovation

• Two mutually-indepen-

dent bins → optional, pro-

grammable access to all

waffle trays

• Capacity of up to 100

JEDEC trays → production

is not interrupted when

the tray is changed

• Integral chassis → easy to

couple

• PCB transport height can

be changed with just a few

easy actions

Description

For numerous tray fed com-

ponents we recommend an

automatic tray chang using a

matrix tray changer (MTC).

The MTC set-up is precisely

matched to the placement

sequence in order to opti-

mize the timings and dis-

tances traveled. Two bins

with trays move indepen-

dently of one another in the

vertical direction until the

desired magazine is within

the range of the feed axis.

The horizontal feed axis

transports the tray from the

bin to within the range of the

placement head. The first

magazine is made available

as soon as a PCB moves onto

the PCB conveyor, and valid

panel and set-up data is avail-

able. All other magazine

changes are carried out time-

neutrally during the place-

ment process. The maga-

zines can be refilled without

stopping the machine. Defec-

tive components are re-

turned to the original tray.

Tray supply 2 Tray supply 1

Feed axis 1

Feed axis 2

Component Feeding

Matrix Tray Changer

Technical Data

*) Waffle tray carrier

Tray supply 1 (XL) Tray supply 2

Dimensions

length x width

height

1305 x 600 mm²

1490 mm for 830 mm PCB transport height

1560 mm for 900 mm PCB transport height

1590 mm for 930 mm PCB transport height

1640 mm for 950 mm PCB transport height

Weight (basic equipment) approx. 500 kg (with PCB magazines

and waffle tray carriers)

Weight (fully equipped) approx. 534 kg (with components)

Weight (moving mass) approx. 80 kg approx. 43.5 kg

PCB magazine size (L x W x H) 391.2 x 305.6 x 93.3 mm³ 352.7 x 154.8 x 133.8 mm³

PCB magazine weight

(fully equipped)

(without waffle tray carrier)

approx. 11 kg

approx. 1.7 kg

approx. 7.5 kg

approx. 1.35 kg

Weight of the

waffle tray carrier

850 g 150 g

Dimensions of the

waffle tray carrier (L x W x H)

386.5 x 295.8 x 11.1 mm³ 371 x 146 x 10.1 mm³

Distance from PCB magazine to

magazine

96 mm 135 mm

Distance from level to level 12 mm 11.8 mm

Vertical travel

444 mm (1st to 30th WTC

)

511.2 mm (1st to 40th

WTC

)

Horizontal travel between out-

going and pick-up position

approx. 647 mm approx. 638 mm

Storage capacity 30 XL waffle-pack tray

carriers with 60 JEDEC or

30 special magazines

of maximum size

40 waffle tray carriers with

40 JEDEC waffle trays

Changeover time (over 5 levels) approx. 2 sec approx. 1.5 sec

Max. height of component and

waffle tray, including tolerances

all levels filled

one level free

two levels free

8.5 mm

19.5 mm

31.5 mm

8.5 mm

19.5 mm

Component Feeding

Matrix Tray Changer

Technical Data

Electrical ratings

Noise emissions

Permitted environmental factors

Supply voltage 3 x 400 VAC, 50 Hz (Europe)

3 x 208 VAC, 60 Hz (USA)

Total power 1.5 kW

Rated current 2.7 A at 3 x 400 VAC

4.2 A at 3 x 208 VAC

Fuses 3 x 16 A

Rated current consumption of the largest consumer 2 A

Maximum noise emissions 74 dB (A)

Room temperature between 15 °C and 35 °C

Atmospheric humidity

30 - 75 %

(No higher than 45% on average to prevent any

possibility of condensation on the machine)
