Introduction Brief Description Installation Manual SIPLACE Material ManagerV2.1 5 1 1 I n t r o d u c t io n Introduction 1.1 1 . 1 B r ie f D e s c r ip t io n Brief Description This installation manu al provides instru…
4 Installation Manual SIPLACE Material ManagerV2.1
Introduction
Brief Description
Installation Manual SIPLACE Material ManagerV2.1 5
1
1 Introduction
Introduction
1.1
1.1 Brief Description
Brief Description
This installation manual provides instructions on installing the 2.1 version of the SIPLACE® Material
Manager software.
The installation manual contains information on the scope of delivery and requirements for successful
installation.
1.2
1.2 Scope of Delivery
Scope of Delivery
The delivery contains:
▪ SIPLACE Material Manager Server V2.1, item no. [00117400-xx] including:
– 1 SIPLACE Material Manager Factory License (without machine connections)
▪ SIPLACE Material Manager Media Package V2.1, item no. [00117951-xx] including:
– Software CD ROM SIPLACE Material Manager V2.1
– DVD SIPLACE NET Support Media Version 1.16, item no. [00392803-xx]
– Software Installation Manual SIPLACE Material Manager V2.1, item no.
[00197500-xx]
1.3
1.3 Prerequisites
Prerequisites
Administrator authorization is required to install the Material Manager.
Depending on the expected data volume, the Material Manager can be installed in two different struc
-
tures:
▪ Local Installation
The Material Manager components and the SQL database will be installed on the same server.
▪ Distributed Installation
The Material Manager components will be installed on one server and the SQL database on another,
separate server.
If more than 4 lines are used in your production environment, "Distributed Installation" is recommended
due to the expected data volume and the resulting performance.
NOTICE
To Support Media DVD:
Please use the Navigation Guide button of the Support Media Launcher to navigate through
the documentation.
The navigation guide and all related documents are available on the Support Media DVD.
NOTICE
Service engineers
The installation of the Material Manager always has to be performed by a specially trained ser
-
vice engineer.
Introduction
Prerequisites
6 Installation Manual SIPLACE Material ManagerV2.1
Hardware
▪ The hardware recommended in the release document is required.
Software
▪ Either the server on which you want to install the Material Manager or another server in your network
already has to function as SQL database server.
▪ The server on which you want to install the Material Manager has to be prepared for the Material
Manager by means of the current Support Media DVD.
▪ The necessary system requirements for SIPLACE Material Manager correspond basically to the sys
-
tem requirements for SIPLACE Setup Center and are described in the Version Description SIPLACE
Setup Center, item no. [00197284-xx].
▪ If "Distributed Installation" is used, the MS DTC properties have to be correctly set on the server that
shall function as SQL database server (see section "7 Distributed Installation" [ ➙ 49]).
NOTICE
System requirements
The Support Media DVD included in the installation package checks the necessary system re
-
quirements of your system and installs these. Amongst others e.g. Microsoft .NET Framework,
the License Manager and the Error Reporting tool.
The use of the Support Media V1.16 is obligatory.
The system requirements (supported operating systems and database variants) and an over
-
view of the interoperable products can be found in the SIPLACE Support Media Installation
Manual, item no. [00197214-xx].
