1.
4.4 Enabling Network Control
N O T I C E
If the reset input is active, the soft starter does not operate. If a reset switch is not required, use parameter 7-9 Reset/Enable Logic
to set the reset input to normally open or fit a link across terminals RESET, COM+ on the soft starter.
Procedure
Set parameter 1-1 Command Source to Network for the soft starter to accept commands from the EtherNet/IP Card.
4.5 On-board Web Server
4.5.1 Connect to the Device
To configure settings using the on-board web server, the EtherNet/IP Card must be installed in a soft starter, control power must be
available, and the option card and computer must both be connected to the Ethernet network.
The computer must use a fixed IP address (not DHCP) and the same subnet mask as the option card. The default IP address for the
card is 192.168.0.2. The default subnet mask is 255.255.255.0.
e77ha807.10
Once connected, the web server reports basic information about the card and the soft starter.
AN353423548483en-000201 / 130R0945 | 11Danfoss A/S © 2022.10
Device Configuration
EtherNet/IP Card
Installation Guide
•
•
•
-
-
MCD 600
e77ha812.10
4.5.2 Manage Users and Passwords
N O T I C E
For security reasons, define a custom administrator ID and password. The default username and password are:
Username: danfoss_admin
Password: danfoss_admin
N O T I C E
Version 1.x of the EtherNet/IP Card does not support custom users.
The EtherNet/IP Card supports multiple users and levels of privilege.
Users can view the home screen and IP settings.
Supervisors can view the home screen and IP settings, and they can change configuration settings.
Administrators can view the home screen, change configuration settings, and add or delete users.
AN353423548483en-000201 / 130R094512 | Danfoss A/S © 2022.10
Device Configuration
EtherNet/IP Card
Installation Guide
1.
2.
3.
4.
5.
6.
1.
2.
3.
4.5.2.1 Adding a User
1
2
3
5
6
e77ha808.10
4
Procedure
Connect to the web server and click Administration.
Click Create new user.
Enter the new username and password.
Click Create an account.
Set privileges (user, supervisor, administrator) as appropriate.
Click Save changes.
4.5.2.2 Deleting a User
Procedure
Connect to the web server and click Administration.
Select the required entry in the user list and click Delete.
Click Delete again to confirm the action.
AN353423548483en-000201 / 130R0945 | 13Danfoss A/S © 2022.10
Device Configuration
EtherNet/IP Card
Installation Guide
