See the chapter Parameter Lists for more details.
7.2.2.2 Class 103 Objects (Read Only)
Class 103d (0x67) allows soft starter state information to be read from the soft starter.
N O T I C E
For models MCD6-0063B and smaller, current reported via communications is 10 times greater than the actual value shown on
the LCP.
Table 6: Objects to be Read from the Soft Starter
Object name
Class
Instance
Attribute
Binary protocol version
103
100
100
Product type code
103
101
100
Reserved
103
102
100
Reserved
103
103
100
Soft starter model
103
104
100
Changed parameter number
103
105
100
Number of parameters
103
106
100
Changed parameter value
103
107
100
Reserved
103
108
100
Soft starter state
1 = Ready
2 = Starting
3 = Running
4 = Stopping (including braking)
5 = Restart delay (including temperature check)
6 = Tripped
7 = Programming mode
8 = Jog forward
9 = Jog reverse
103
109
100
Warning
0 = No warning
1 = Warning
103
110
100
Initialized
1 = Phase sequence is valid
103
111
100
Phase sequence
(1 = Positive phase sequence, only valid if Initialized = 1)
103
112
100
Reserved
103
113
100
Reserved
103
114
100
Trip/Warning code (see the chapter Trip Codes)
103
115
100
Average rms current across all 3 phases
103
116
100
AN353423548483en-000201 / 130R0945 | 23Danfoss A/S © 2022.10
Messaging
EtherNet/IP Card
Installation Guide
Object name
Class
Instance
Attribute
Current (% motor FLC)
103
117
100
Motor temperature
103
118
100
Reserved
103
119
100
Power
103
120
100
Power scale
0 = Multiply power by 10 to get W
1 = Multiply power by 100 to get W
2 = Power (kW)
3 = Multiply power by 10 to get kW
103
121
100
% Power factor
103
122
100
Average rms voltage across all 3 phases
103
123
100
Phase 1 current
103
124
100
Phase 2 current
103
125
100
Phase 3 current
103
126
100
Phase 1 voltage
103
127
100
Phase 2 voltage
103
128
100
Phase 3 voltage
103
129
100
Parameter list minor version
103
130
100
Parameter list major version
103
131
100
Digital input state
For all inputs, 0 = open, 1 = closed (short-circuited)
Start/stop input = 01h, reset = 04h, programmable input A = 08h, programmable input B = 10h
103
132
100
Trip code
103
133
100
Reserved
103
134
100
Frequency
103
135
100
Ground current
103
136
100
N O T I C E
The reset input is normally closed by default. If parameter 7-9 Reset/Enable Logic is set to normally open, the reported state is
inverted (0 = closed, 1 = open).
7.2.2.3 Class 104 Objects (Read Only)
Class 104d (0x68) allows extended information to be read from the soft starter.
Object name
Class
Instance
Attribute
Major software version - User interface
104
101
100
Minor software version - User interface
104
102
100
AN353423548483en-000201 / 130R094524 | Danfoss A/S © 2022.10
Messaging
EtherNet/IP Card
Installation Guide
•
•
Object name
Class
Instance
Attribute
Major software version - Motor control
104
103
100
Minor software version - Motor control
104
104
100
Major software version - Remote LCP (if installed)
104
105
100
Minor software version - Remote LCP (if installed)
104
106
100
Major software version - Expansion card (if installed)
104
107
100
Minor software version -. Expansion card (if installed)
104
108
100
7.2.3 Supported Services for Vendor-specific Objects
This section describes the operational instructions to carry out acyclic services on class objects 100, 101, 102, 103, and 104.
7.2.3.1 Service Codes for Acyclic Operation
Table 7: Supported Services for Vendor-specific Objects
Service code
Function
Description
01d (0x01)
Get attribute all
Only supported for class 0x01 identity object
10d (0x10)
Set attribute single
Supported
15d (0x0E)
Get attribute single
Supported
7.2.3.2 Status Codes for Acyclic Services
Table 8: Status Codes Returned in Response to Get/Set Attribute Single
Status code
Status name
Details
00d (0x00)
Success
This code is returned when:
the register mapped for "Get Attribute Single" is successfully read.
the register mapped for "Set Attribute Single" is successfully set.
03d (0x03)
Invalid parameter value
–
05d (0x05)
Path destination unknown
The mapped register does not exist.
08d (0x08)
Service not supported
The requested service is not available for this object class/instance.
09d (0x09)
Invalid attribute value
This code only applies to the service Set Attribute Single. It is returned if the value is
out of range of the mapped register.
15d (0x0E)
Attribute not settable
This code only applies to the service Set Attribute Single. It is returned if the mapped
register is read-only.
20d (0x14)
Attribute not supported
The attribute specified in the request is not supported.
22d (0x16)
Object does not exist
The object specified does not exist in the device.
AN353423548483en-000201 / 130R0945 | 25Danfoss A/S © 2022.10
Messaging
EtherNet/IP Card
Installation Guide
