N O T I C E
The numbering of parameter options via communications starts at 0. For Phase Sequence, 0 = Any sequence, 1 = Positive only, 2
= Negative only.
8.2.1 Parameters, Class 100, Class 101, and Class 102 Objects (Read/Write)
Table 9: Objects with Class, Instance, and Attribute (Read/Write)
Object name
Class
Instance
Attribute
Object name
Class
Instance
Attribute
Class 100 objects
Motor kW-2
100
127
100
Motor details
Start Mode-2
100
128
100
Command Source
100
101
100
Start Ramp Time-2
100
129
100
Motor Full Load Current
100
102
100
Initial Current-2
100
130
100
Motor kW
100
103
100
Current Limit-2
100
131
100
Locked Rotor Time
100
104
100
Adaptive Start Profile-2
100
132
100
Locked Rotor Current
100
105
100
Kickstart Time-2
100
133
100
Motor Service Factor
100
106
100
Kickstart Level-2
100
134
100
Reserved
100
107
100
Jog Torque-2
100
135
100
Motor start/stop
Stop Mode-2
100
136
100
Start Mode
100
108
100
Stop Time-2
100
137
100
Start Ramp Time
100
109
100
Adaptive Stop Profile-2
100
138
100
Initial Current
100
110
100
Adaptive Control Gain-2
100
139
100
Current Limit
100
111
100
Multi Pump-2
100
140
100
Adaptive Start Profile
100
112
100
Start Delay-2
100
141
100
Kickstart Time
100
113
100
DC Brake Torque-2
100
142
100
Kickstart Level
100
114
100
DC Brake Time-2
100
143
100
Jog Torque
100
115
100
Brake Current Limit-2
100
144
100
Stop Mode
100
116
100
Soft Brake Delay-2
100
145
100
Stop Time
100
117
100
Auto-start/stop
Adaptive Stop Profile
100
118
100
Auto-Start/Stop Mode
100
146
100
Adaptive Control Gain
100
119
100
Run Time
100
147
100
Multi Pump
100
120
100
Stopped Time
100
148
100
Start Delay
100
121
100
Sunday Mode
100
149
100
DC Brake Torque
100
122
100
Sunday Start Time
100
150
100
DC Brake Time
100
123
100
Sunday Stop Time
100
151
100
Brake Current Limit
100
124
100
Monday Mode
100
152
100
