Object name
Class
Instance
Attribute
Current (% motor FLC)
103
117
100
Motor temperature
103
118
100
Reserved
103
119
100
Power
103
120
100
Power scale
0 = Multiply power by 10 to get W
1 = Multiply power by 100 to get W
2 = Power (kW)
3 = Multiply power by 10 to get kW
103
121
100
% Power factor
103
122
100
Average rms voltage across all 3 phases
103
123
100
Phase 1 current
103
124
100
Phase 2 current
103
125
100
Phase 3 current
103
126
100
Phase 1 voltage
103
127
100
Phase 2 voltage
103
128
100
Phase 3 voltage
103
129
100
Parameter list minor version
103
130
100
Parameter list major version
103
131
100
Digital input state
For all inputs, 0 = open, 1 = closed (short-circuited)
Start/stop input = 01h, reset = 04h, programmable input A = 08h, programmable input B = 10h
103
132
100
Trip code
103
133
100
Reserved
103
134
100
Frequency
103
135
100
Ground current
103
136
100
N O T I C E
The reset input is normally closed by default. If parameter 7-9 Reset/Enable Logic is set to normally open, the reported state is
inverted (0 = closed, 1 = open).
7.2.2.3 Class 104 Objects (Read Only)
Class 104d (0x68) allows extended information to be read from the soft starter.
Object name
Class
Instance
Attribute
Major software version - User interface
104
101
100
Minor software version - User interface
104
102
100
AN353423548483en-000201 / 130R094524 | Danfoss A/S © 2022.10
Messaging
EtherNet/IP Card
Installation Guide
•
•
Object name
Class
Instance
Attribute
Major software version - Motor control
104
103
100
Minor software version - Motor control
104
104
100
Major software version - Remote LCP (if installed)
104
105
100
Minor software version - Remote LCP (if installed)
104
106
100
Major software version - Expansion card (if installed)
104
107
100
Minor software version -. Expansion card (if installed)
104
108
100
7.2.3 Supported Services for Vendor-specific Objects
This section describes the operational instructions to carry out acyclic services on class objects 100, 101, 102, 103, and 104.
7.2.3.1 Service Codes for Acyclic Operation
Table 7: Supported Services for Vendor-specific Objects
Service code
Function
Description
01d (0x01)
Get attribute all
Only supported for class 0x01 identity object
10d (0x10)
Set attribute single
Supported
15d (0x0E)
Get attribute single
Supported
7.2.3.2 Status Codes for Acyclic Services
Table 8: Status Codes Returned in Response to Get/Set Attribute Single
Status code
Status name
Details
00d (0x00)
Success
This code is returned when:
the register mapped for "Get Attribute Single" is successfully read.
the register mapped for "Set Attribute Single" is successfully set.
03d (0x03)
Invalid parameter value
–
05d (0x05)
Path destination unknown
The mapped register does not exist.
08d (0x08)
Service not supported
The requested service is not available for this object class/instance.
09d (0x09)
Invalid attribute value
This code only applies to the service Set Attribute Single. It is returned if the value is
out of range of the mapped register.
15d (0x0E)
Attribute not settable
This code only applies to the service Set Attribute Single. It is returned if the mapped
register is read-only.
20d (0x14)
Attribute not supported
The attribute specified in the request is not supported.
22d (0x16)
Object does not exist
The object specified does not exist in the device.
AN353423548483en-000201 / 130R0945 | 25Danfoss A/S © 2022.10
Messaging
EtherNet/IP Card
Installation Guide
8 Attributes
8.1 Trip Codes
Code
Description
0
No trip
11
Input A trip
20
Motor overload
21
Heatsink overtemperature
23
L1 phase loss
24
L2 phase loss
25
L3 phase loss
26
Current imbalance
27
Ground fault
28
Overcurrent
29
Undercurrent
50
Power loss
51
Undervoltage
52
Overvoltage
54
Phase sequence
55
Frequency
60
Incorrect control card
61
FLC out of range
62
EEPROM fail (parameter out of range)
75
Motor thermistor
101
Excess start time
102
Motor connection
104
Internal fault
110
Input B trip
113
Communications card fault
114
Network communication
115
L1-T1 shorted
116
L2-T2 shorted
117
L3-T3 shorted
119
Bypass overload
