11 Specifications 11.1 Connections Soft starter 6-way pin assembly Contacts Gold flash Network RJ45 11.2 Settings IP address Automatically assigned, configurable Device name Automatically assigned, configurable 11.3 Netw…
e77ha631.10
Illustration 6: Example of Combined Topologies
AN353423548483en-000201 / 130R094536 | Danfoss A/S © 2022.10
Network Design
EtherNet/IP Card
Installation Guide
11 Specifications
11.1 Connections
Soft starter
6-way pin assembly
Contacts
Gold flash
Network
RJ45
11.2 Settings
IP address
Automatically assigned, configurable
Device name
Automatically assigned, configurable
11.3 Network
Link speed
10 Mbps, 100 Mbps (auto-detect)
Full duplex
Auto crossover
11.4 Power
Consumption (steady state, maximum)
35 mA@24 V DC
Reverse polarity protected
Galvanically isolated
11.5 Certification
RCM
IEC 60947-4-2
CE
EN 60947-4-2
ODVA
Illustration 7: ODVA
AN353423548483en-000201 / 130R0945 | 37Danfoss A/S © 2022.10
Specifications
EtherNet/IP Card
Installation Guide
AN353423548483en-000201 / 130R0945
*M0025501*
Danfoss A/S © 2022.10
