DeltaTherm IR Cure Module
Revision C / September 2022
Page 21 of 41
Conveyor Speed
211B210B210BThe Conveyor Speed can be set in Manual mode.
1. 76B75B75BSelect the Speed box to manually enter conveyor speed. The metric/standard u nit
range is .03 – 15.3m/min (.1 - 50.2ft/min).
• 77B76B76BThe keypad will be shown, enter the necessary value.
• 78B77B77BSelect ‘ENT’ to save.
2. 79B78B78BPress the red X icon or green checkmark icon to toggle the conveyor
between on and off.
212B211B211B
12B12B12BFigure 13: Conveyor Control in Manual Mode
Conveyor Width
213B212B212B
13B13B13BFigure 14: Conveyor Width in Manual Mode
DeltaTherm IR Cure Module
Revision C / September 2022
Page 22 of 41
214B213B213BThe Conveyor Width can be set in Manual mode.
1. 80B79B79BPress to manually enter the target conveyor width setpoint.
• 81B80B80BTouch the screen and a keypad will be shown.
• 82B81B81BEnter the necessary value.
• 83B82B82BPush ‘ENT’, and the zone screen will be shown again.
2. 84B83B83BPress to move the current target conveyor width setpoint.
276B275B275BNote: Prior to the move, the machine will check for any boards.
3. 85B84B84BPress to rehome the conveyor width.
277B276B276BNote: Prior to the move, the machine will check for any boards.
Conveyor Jog
215B214B214B
14B14B14BFigure 15: Conveyor Jog in Manual Mode
1. 86B85B85BThis screen displays the current conveyor width.
2. 87B86B86BPress to adjust the conveyor width. This will jog the conveyor width in a positive or
negative direction.
278B277B277BNote: The clearboard sequence will not run prior to the jog.
DeltaTherm IR Cure Module
Revision C / September 2022
Page 23 of 41
Sensors
216B215B215BThe PIP Sensors can be monitored in Manual mode for correct operation.
217B216B216B
15B15B15BFigure 16: Sensors in Manual Mode
279B278B278BNote: Process PIP will only show on 12 ft and 16 ft oven length systems.
SMEMA Control
1. 88B87B87BThe SMEMA inputs (Upstream Board Available and Downstream Ready) can be
monitored for correct operation through the SMEMA screen in Manual mode.
2. 89B88B88BSelect the necessary output (Machine Ready and Board Available) to toggle it on or
off.
218B217B217B
16B16B16BFigure 17: SMEMA in Manual Mode
