DeltaTherm IR Cure Module
Revision C / September 2022
Page 5 of 41
Introduction
163B162B162BBefore you operate this system, read the operation and setup manual. This will help you to
become familiar with the product and ensure successful operation.
164B163B163BIf any questions or problems arise, contact PVA’s Technical Support department.
PVA Contact Information
165B164B164BMain Office PVA
166B165B165BOne Mustang Drive
167B166B166BCohoes, NY 12047
168B167B167BTel +1-518-371-2684
169B168B168BFax +1-518-371-2688
170B169B169BWebsite: https://pva.net
171B170B170BEmail: info@pva.net
172B171B171BTechnical Support
173B172B172BTel +1-844-734-0209
174B173B173BEmail: cs@pva.net
Document History
Revision
Revision Date
Reason for Changes
REV C
September 2022
Exhaust Requirement Update
REV B
January 2020
DeltaTherm Version 1.9 Release
REV A
December 2018
Initial Release
267B266B266BNote: All photographs and CAD model representations in this document are a
“general representation” of the system and its components. The actual appearance
of the system and its components can differ based upon customer specific
configuration.
DeltaTherm IR Cure Module
Revision C / September 2022
Page 6 of 41
Safety
175B174B174BCertain warning symbols are affixed to the machine and correspond to notations in this
manual. Before operating the system, identify these warning labels and read the notices
described below. Not all labels may be used on any specific system.
Always wear approved safety glasses when you operate or work near the
workcell.
Before you operate the system, read and understand the manuals provided
with the unit.
Never put hands or tools in areas with this symbol when the machine is in
operation. A dangerous condition may exist.
Read and understand the manuals provided with the unit before any repairs
or maintenance is done. Only a qualified individual should do service.
Use caution when there are pressurized vessels. Find and repair any leaks
immediately. Always wear appropriate safety equipment when you work
with pressurized vessels or vessels that contain chemicals
Shear hazard from moving parts. Avoid contact.
Do not remove protective guarding.
In situations where inattention could cause either personal injury or damage
to equipment, a warning notice is used.
