DeltaTherm IR Cure Module
Revision C / September 2022
Page 33 of 41
151
Panel 6B Overtemp >285C
152
Panel 7A Overtemp >285C
153
Panel 7B Overtemp >285C
154
Panel 8A Overtemp >285C
155
Panel 8B Overtemp >285C
156
Zone 1A Intensity Fault Panel Never Reached Setpoint
157
Zone 1B Intensity Fault Panel Never Reached Setpoint
158
Zone 2A Intensity Fault Panel Never Reached Setpoint
159
Zone 2B Intensity Fault Panel Never Reached Setpoint
160
Zone 3A Intensity Fault Panel Never Reached Setpoint
161
Zone 3B Intensity Fault Panel Never Reached Setpoint
162
Zone 4A Intensity Fault Panel Never Reached Setpoint
163
Zone 4B Intensity Fault Panel Never Reached Setpoint
164
Zone 5A Intensity Fault Panel Never Reached Setpoint
165
Zone 5B Intensity Fault Panel Never Reached Setpoint
166
Zone 6A Intensity Fault Panel Never Reached Setpoint
167
Zone 6B Intensity Fault Panel Never Reached Setpoint
168
Zone 7A Intensity Fault Panel Never Reached Setpoint
169
Zone 7B Intensity Fault Panel Never Reached Setpoint
170
Zone 8A Intensity Fault Panel Never Reached Setpoint
171
Zone 8B Intensity Fault Panel Never Reached Setpoint
173
Zone 1A Deviation Fault
174
Zone 1B Deviation Fault
175
Zone 2A Deviation Fault
176
Zone 2B Deviation Fault
177
Zone 3A Deviation Fault
178
Zone 3B Deviation Fault
179
Zone 4A Deviation Fault
180
Zone 4B Deviation Fault
181
Zone 5A Deviation Fault
182
Zone 5B Deviation Fault
DeltaTherm IR Cure Module
Revision C / September 2022
Page 34 of 41
183
Zone 6A Deviation Fault
184
Zone 6B Deviation Fault
185
Zone 7A Deviation Fault
186
Zone 7B Deviation Fault
187
Zone 8A Deviation Fault
188
Zone 8B Deviation Fault
190
Master Conveyor Transfer (CAN3) Drive Mapping Fault
191
Master Conveyor Width (CAN4) Drive Mapping Fault
192
Slave Conveyor Transfer (CAN5) Drive Mapping Fault
193
Slave Conveyor Width (CAN6) Drive Mapping Fault
300
Conveyor Transfer (CAN3) Drive Enable Fault Initialization Failed
301
Conveyor Width (CAN4) Drive Enable Fault Initialization Failed
302
Conveyor Transfer (CAN5) Drive Enable Fault Initialization Failed
303
Conveyor Width (CAN6) Drive Enable Fault Initialization Failed
304
Conveyor Transfer (CAN3) Drive Enable Fault Ready to Switch On State Failed
305
Conveyor Width (CAN4) Drive Enable Fault Ready to Switch On State Failed
306
Conveyor Transfer (CAN5) Drive Enable Fault Ready to Switch On State Failed
307
Conveyor Width (CAN6) Drive Enable Fault Ready to Switch On State Failed
308
Conveyor Transfer (CAN3) Drive Enable Fault Switch On State Failed
309
Conveyor Width (CAN4) Drive Enable Fault Switch On State Failed
310
Conveyor Transfer (CAN5) Drive Enable Fault Switch On State Failed
311
Conveyor Width (CAN6) Drive Enable Fault Switch On State Failed
312
Conveyor Transfer (CAN3) Drive Enable Fault Operation Enabled State Failed
313
Conveyor Width (CAN4) Drive Enable Fault Operation Enabled State Failed
314
Conveyor Transfer (CAN5) Drive Enable Fault Operation Enabled State Failed
315
Conveyor Width (CAN6) Drive Enable Fault Operation Enabled State Failed
316
Conveyor Width (Master) Drive Runaway Fault
317
Conveyor Width (Slave) Drive Runaway Fault
22BFigure 23: Error Messages
DeltaTherm IR Cure Module
Revision C / September 2022
Page 35 of 41
Troubleshooting
233B232B232BIf Something Goes Wrong . . .
234B233B233BSome problems are easy to identify and solve, others may require more extensive help. This
troubleshooting section is designed to assist an operator in solving many problems before
seeking additional help.
235B234B234BRefer to this Troubleshooting section if a mechanical or electrical problem occurs before
you call Technical Support.
Calling Technical Support
236B235B235BThe Technical Support staff is available to help solve any problems. The phone number is
+1 518-371-2684. Have the following information when you call for help:
• 153B152B152BAll the information on the OIT when the error occurred.
• 154B153B153BThe operation in progress when the machine developed trouble (when did it have
problems, what was it doing, etc.).
• 155B154B154BIf the error was not serious, attempt to repeat the error. If the error does not repeat,
the problem may have been operator generated.
