Page 15
V/S Standard Insertion Head Assembly T50090901 Rev. F
This Document Supports Assembly 50090901 Rev. D
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
1 10249029 SPRING,COMPRESSION 2 EA
2 10249391 SPRING,COMPRESSION 1 EA
3 10249400 SPRING,COMPRESSION 2 EA
4 10249404 SPRING,COMPRESSION 2 EA
5 10249423 SPRING,COMPRESSION 2 EA
6 10457013 CLAMP,STEEL COLLAR 2 EA
7 10463013 SHOULDER SCREW 1 EA
8 10463073 SHOULDER SCREW 1 EA
9 10595001 BEARING,THRUST 4 EA
10 10894154 SPRING, EXTENSION 2 EA
11 12511000 SHAFT 1 EA
12 12534000 BUSHING,BALL 4 EA
13 12539000 BUSHING,BALL 2 EA
14 13155000 BEARING, BALL 1 EA
15 26462017 SCREW,SHOULDER 4 EA
16 30659511 FITTING,STRAIGHT 4 EA
17 40075447 O-RING 4 EA
18 40226506 SPACER 2 EA
19 40226508 SPACER 2 EA
20 40264001 SCREW,JACK 1 EA
21 40264101 BLOCK,ADJ 1 EA
22 40264201 JACK 1 EA
23 40298403 SHAFT 1 EA
24 40413106 RET RING 5100-39 1 EA
25 40511001 SPROCKET 2 EA
26 40511204 BEARING,NEEDLE ROLLER 2 EA
27 40532501 IMPULSE COUNTER ASSY 1 EA
28 40579701 WASHER,THRUST 10 EA
29 40579702 WASHER,THRUST 2 EA
30 40622503 WASHER,PLATE 2 EA
Page 16
T50090901 Rev. F V/S Standard Insertion Head Assembly
This Document Supports Assembly 50090901 Rev. D
31 40834510 FITTING, GREASE 2 EA
32 41303005 CYLINDER,DBL ACTNG AIR 2 EA
33 42239901 RT ANG LUMINATOR ASM 1 EA
34 42961103 BLOCK,RAISE 2 EA
35 42961405 BAR,RAISE 2 EA
36 43261506 FITTING, UNION TEE 2 EA
37 44241611 BLOCK,SHEAR 2 EA
38 45016701 SHAFT 1 EA
39 45593002 DETENT 4 EA
40 46193302 LOCKING ELEMENT 2 EA
41 46269205 BEARING, RADIAL 4 EA
42 46269211 BEARING, RADIAL 1 EA
43 46442715 BELT,TIMING 1 EA
44 46442717 BELT,TIMING 2 EA
45 46442718 BELT,TIMING 1 EA
46 46614204 PINION 1 EA
47 46614305 SHAFT PINION 1 EA
48 46644203 HOLDER, SPRING 2 EA
49 46669501 PLATE, MOTOR 1 EA
50 49752201 LEAD SCREW, HEAD 1 EA
51 46737501 LOCKNUT 2 EA
52 46805213 BLADE,SHEAR STD LH 1 EA
53 46805306 DRIVERBODY,L 1 EA
54 46805406 FORMER , STD LEFT 1 EA
55 46805502 RAIL,L FRONT 1 EA
56 46805603 RAIL,L REAR 1 EA
57 46806213 BLADE,SHEAR STD RH 1 EA
58 46806306 DRIVERBODY,R 1 EA
59 46806406 FORMER , STD RIGHT 1 EA
60 46806502 RAIL,R FRONT 1 EA
61 46806603 RAIL,R REAR 1 EA
62 46807101 RAIL,CAM 2 EA
Page 17
V/S Standard Insertion Head Assembly T50090901 Rev. F
This Document Supports Assembly 50090901 Rev. D
63 46807302 PLATE 2 EA
64 46807401 PLATE,SPACER 2 EA
65 46952401 BEARING,BALL,CLAMP 2 EA
66 46970201 MOTOR,BRUSHLESS,DC 1 EA
67 46970202 MOTOR,BRUSHLESS,DC 1 EA
68 46992501 COUPLING 1 EA
69 47085501 DRIVER TIP,L 1 EA
70 47085601 DRIVER TIP,R 1 EA
71 47085901 KEY, .190 2 EA
72 47513004 BRACKET,FIBER OPTIC 1 EA
73 47558501 CBL,FIBER OPTIC,2M,FLEX 1 EA
74 47610003 HOUSING,VCD/SEQ MACH 1 EA
75 47610701 SENSOR ASSY 1 EA
76 47612505 PLATE,IDLER L 1 EA
77 47612605 PLATE,IDLER R 1 EA
78 47612701 HOLDER,SPRING L 1 EA
79 47612801 HOLDER,SPRING R 1 EA
80 47614301 PULLEY, GEARBELT 1 EA
81 47614401 PULLEY,GEARBELT 1 EA
82 47614501 PULLEY,GEARBELT 1 EA
83 47614502 PULLEY,GEARBELT 1 EA
84 47614602 PULLEY,GEARBELT 2 EA
85 47614901 BRACKET,MTR MTG 1 EA
86 47630001 SHAFT, PIVOT 1 EA
87 47630102 BUSHING, ECCENTRIC 1 EA
88 47630202 HOUSING,CENTERING 1 EA
89 47630301 KEY,SPRING,SUPPORT 1 EA
90 47630701 SHAFT,CAM 1 EA
91 47630915 INSERT, CENTERING 2 EA
92 47631004 CAM,30/135 CENTERING 1 EA
93 47631101 TENSION ARM ASSY 1 EA
94 47631201 BUSHING 1 EA
