Page 21 V/S Standard Insertion Head Assembly T50090901 Rev . F This Document Supports Assembly 50090901 Rev. D 191 BLKE01072 CLAMP,1/4" 3 EA 192 BLKE01074 CLAMP,3/8",BLACK 2 EA 193 BLKM05001 BR G,THR.507ID,.75O…

100%1 / 78
Page 20
T50090901 Rev. F V/S Standard Insertion Head Assembly
This Document Supports Assembly 50090901 Rev. D
159 80000613 SHCS 1/4-20 X 2 1/2 2 EA
160 80000708 SHCS 5/16-18 X 1 1/2 1 EA
161 80001402 SBHS 6-32 X 3/8 4 EA
162 80001501 SBHS 8-32 X 1/4 4 EA
163 80001502 SBHS 8-32 X 3/8 12 EA
164 80001603 SBHS 10-24 X 1/2 2 EA
165 80001716 SBHS 1/4-28 X 1 1/2 2 EA
166 80001803 SBHS 5/16-18 X 5/8 1 EA
167 80002207 SFHS 4-40 X 5/16 2 EA
168 80002401 SFHS 6-32 X 1/4 2 EA
169 80002501 SFHS 8-32 X 3/8 10 EA
170 80002502 SFHS 8-32 X 1/2 2 EA
171 80003702 SSSCPP 8-32 X 3/16 2 EA
172 80003802 SSSCPP 10-24 X 1/4 5 EA
173 80003812 SSSCPP 10-32 X 1/4 4 EA
174 80003814 SSSCPP 10-32 X 3/8 2 EA
175 80003903 SSSCPP 1/4-20 X 5/16 2 EA
176 40834320 SPIROL PIN, LIGHT DUTY 2 EA
177 80014310 SPRG PIN .187 X 1.000 1 EA
178 80015102 HEX JAM NUT 1/4-28 2 EA
179 80018705 SLW #10 6 EA
180 80018706 SLW 1/4 21 EA
181 80018802 FW #4 4 EA
182 80018803 FW #6 2 EA
183 80018804 FW #8 2 EA
184 80018807 FW 1/4 8 EA
185 80022201 SHCS-LH 10-24 X 3/8 4 EA
186 80023502 HEX NUT-MS 4-40 2 EA
187 80023505 HEX NUT-MS 8-32 2 EA
188 80023507 HEX NUT-MS 10-24 1 EA
189 80023508 HEX NUT-MS 10-32 2 EA
190 BLKE01071 CLAMP,3/16" 6 EA
Page 21
V/S Standard Insertion Head Assembly T50090901 Rev. F
This Document Supports Assembly 50090901 Rev. D
191 BLKE01072 CLAMP,1/4" 3 EA
192 BLKE01074 CLAMP,3/8",BLACK 2 EA
193 BLKM05001 BRG,THR.507ID,.75OD,.062W 6 EA
194 BLKM05318 FITTING, ADJUSTABLE L 4 EA
195 BLKM06300 RET RING 5133-25 1 EA
196 BLKM06303 RET RING 5100-12 4 EA
197 BLKM06316 RING, RETAINING 4 EA
198 BLKM06331 RING, RETAINING 2 EA
199 BLKM07117 WASHER, THRUST 2 EA
200 80018704 SLW #8 2 EA
201 50276301 LABEL, DO NOT GREASE LEADSCREW 1 EA
202 40835930 TUBING, POLY, 5/32 YELLOW 2.16 FT
203 40835932 TUBING, POLY, 5/32 BLUE 2.16 FT
204 BLKE01630 TIE, CABLE 1 EA
205 T50090901 DOC,V/S STD HD ASSY 1 EA
USED BUT NOT SHOWN ITEMS
Page 22
T50090901 Rev. F V/S Standard Insertion Head Assembly
This Document Supports Assembly 50090901 Rev. D
Functional Description
The insertion head assembly contains the tooling housing assemblies, cen-
tering assembly, head drive, span drive, head chain drive, part missing detec-
tor and the BEC light source. The span axis drive positions the housing as-
semblies to the desired insertion span. When the head chain drive is actu-
ated, the head chain advances a component under the insertion tooling.
When the head drive motor is actuated, the tooling assemblies, located in the
housings, are driven down and the component centering is actuated. As the
tooling is driven down, it cuts, forms, guides and inserts the component
through the board.
Maintenance Concept
The following table defines the recommended Maintenance Concept for this
assembly. For a more detailed explanation of the Maintenance Concept and
its structure, refer to the Prerequisite Information/Introduction module and
the periodic preventive maintenance described later in this document.
Maintenance Procedures
Recommended
Frequency
Minimum Skill
Required
Spares Kit
Required
Tool Kit
Required
Lubricate tooling driver bodies
500,000
Maintenance
Technicia
n
No No
Remove, disassemble, clean and
lubricate the insertion tooling
3,000,000
Maintenance
Technician
No Yes
Check, clean and lubricate drive pinion
and driver body racks
3,000,000
Maintenance
Technician
No No
Check, clean and lubricate centering
cam surfaces
3,000,000
Maintenance
Technician
No No
Lubricate insertion head lead screw
12,000,000
Maintenance
Technician
No No
Clean the insertion head tooling
housings
12,000,000
Maintenance
Technician
No Yes
Inspect all belts for wear and correct
tension
36,000,000
Maintenance
Technician
Yes No
Remove, disassemble, clean and
lubricate the insertion head
36,000,000
Maintenance
Technician
No Yes
Clean and lubricate the centering
assembly pivot points
36,000,000
Maintenance
Technician
No Yes
Lubricate grease fittings
144,000,000
Maintenance
Technicia
n
No No
Clean and lubricate the lower sprockets
144,000,000
Maintenance
Technician
No No
