Page 17
V/S Standard Insertion Head Assembly T50090901 Rev. F
This Document Supports Assembly 50090901 Rev. D
63 46807302 PLATE 2 EA
64 46807401 PLATE,SPACER 2 EA
65 46952401 BEARING,BALL,CLAMP 2 EA
66 46970201 MOTOR,BRUSHLESS,DC 1 EA
67 46970202 MOTOR,BRUSHLESS,DC 1 EA
68 46992501 COUPLING 1 EA
69 47085501 DRIVER TIP,L 1 EA
70 47085601 DRIVER TIP,R 1 EA
71 47085901 KEY, .190 2 EA
72 47513004 BRACKET,FIBER OPTIC 1 EA
73 47558501 CBL,FIBER OPTIC,2M,FLEX 1 EA
74 47610003 HOUSING,VCD/SEQ MACH 1 EA
75 47610701 SENSOR ASSY 1 EA
76 47612505 PLATE,IDLER L 1 EA
77 47612605 PLATE,IDLER R 1 EA
78 47612701 HOLDER,SPRING L 1 EA
79 47612801 HOLDER,SPRING R 1 EA
80 47614301 PULLEY, GEARBELT 1 EA
81 47614401 PULLEY,GEARBELT 1 EA
82 47614501 PULLEY,GEARBELT 1 EA
83 47614502 PULLEY,GEARBELT 1 EA
84 47614602 PULLEY,GEARBELT 2 EA
85 47614901 BRACKET,MTR MTG 1 EA
86 47630001 SHAFT, PIVOT 1 EA
87 47630102 BUSHING, ECCENTRIC 1 EA
88 47630202 HOUSING,CENTERING 1 EA
89 47630301 KEY,SPRING,SUPPORT 1 EA
90 47630701 SHAFT,CAM 1 EA
91 47630915 INSERT, CENTERING 2 EA
92 47631004 CAM,30/135 CENTERING 1 EA
93 47631101 TENSION ARM ASSY 1 EA
94 47631201 BUSHING 1 EA
Page 18
T50090901 Rev. F V/S Standard Insertion Head Assembly
This Document Supports Assembly 50090901 Rev. D
95 47631301 SPRING,TORSION 1 EA
96 47631402 PULLEY, CENTERING, DRIVEN 1 EA
97 47631501 PULLEY,CENTERING DRIVER 1 EA
98 47631601 PIN, LOCATOR 1 EA
99 47631701 BRACKET, BEC 1 EA
100 47631901 PIN, FOLLOWER 1 EA
101 47632002 PIN,PIVOT,FINGER 2 EA
102 47632601 KEY, DRIVE, CAM 6 EA
103 47632702 GUIDE, CHAIN CLIP 2 EA
104 47632801 SPROCKET,LOWER 2 EA
105 47632902 SHAFT, LOWER 2 EA
106 47633001 SHAFT, IDLER 1 EA
107 47633101 BEARING, RADIAL 2 EA
108 47633201 5101 SERIES RET RING 2 EA
109 47633301 SHAFT,FINGER 2 EA
110 47636601 CLAMP, COLLAR 3 EA
111 47636602 CLAMP, COLLAR 2 EA
112 47636701 COUPLING 1 EA
113 47636801 PLATE,NUT 1 EA
114 47637002 BRACKET,MOTOR MOUNT 1 EA
115 47637101 STOP,ZERO SPAN 1 EA
116 47637701 BRACKET,MOTOR MOUNTING 1 EA
117 47638001 PLATE,SPRING 1 EA
118 47639701 BRACKET,HEAD COUNTER 1 EA
119 47668103 HOUSING, L VCD TLNG 1 EA
120 47668203 HOUSING,R VCD TLNG 1 EA
121 47702101 MOTOR:BRUSHLESS:DC:ENCDR 1 EA
122 49764501 FINGER,LH CENTERING 1 EA
123 49764502 FINGER,RH CENTERING 1 EA
124 47768001 BLOCK, LIGHT SOURCE 2 EA
125 47792001 BEARING, RADIAL 2 EA
126 47844801 PLUNGER,SPRING 1 EA
Page 19
V/S Standard Insertion Head Assembly T50090901 Rev. F
This Document Supports Assembly 50090901 Rev. D
127 47844903 GUIDE, CHAIN CLIP 2 EA
128 47847201 SPACER 2 EA
129 47897601 PIN, TOOLING 2 EA
130 47898701 FORMER, R INSIDE 1 EA
131 47898801 FORMER,L INSIDE 1 EA
132 47999601 CHAIN IDLER PULLEY ASSY 2 EA
133 49804101 PIN, PINION 1 EA
134 BLKM07121 WSHR.WAVE SPRG.265ID.367OD.006 1 EA
135 48215501 PIN,LIFT 2 EA
136 49399601 ARM,STD R KICKOUT 1 EA
137 49399701 ARM,STD L KICKOUT 1 EA
138 49433901 KEY, .125 SQUARE 1 EA
139 80000103 SHCS 4-40 X 3/8 8 EA
140 80000104 SHCS 4-40 X 1/2 4 EA
141 80000112 SHCS 4-40 X 1 1/2 4 EA
142 80000301 SHCS 6-32 X 1/4 4 EA
143 80000302 SHCS 6-32 X 3/8 2 EA
144 80000306 SHCS 6-32 X 7/8 3 EA
145 80000309 SHCS 6-32 X 1 1/2 1 EA
146 80000402 SHCS 8-32 X 3/8 8 EA
147 80000404 SHCS 8-32 X 5/8 4 EA
148 80000507 SHCS 10-24 X 1 1/4 1 EA
149 80000508 SHCS 10-24 X 1 1/2 6 EA
150 80000509 SHCS 10-24 X 1 3/4 3 EA
151 80000516 SHCS 10-32 X 5/8 4 EA
152 80000517 SHCS 10-32 X 3/4 4 EA
153 80000519 SHCS 10-32 X 1 4 EA
154 80000604 SHCS 1/4-20 X 5/8 1 EA
155 80000605 SHCS 1/4-20 X 3/4 2 EA
156 80000606 SHCS 1/4-20 X 7/8 5 EA
157 80000607 SHCS 1/4-20 X 1 7 EA
158 80000611 SHCS 1/4-20 X 2 3 EA
