4.2.2 File Process

Press the “START/PAUSE” button to begin processing the selected file.

This button also can used to pause a file processing and then continue a file processing.

4.2.3 Stop the File Processing

Press “START/PAUSE” button or Emergency Switch to pause the processing file. START/PAUSE: only pauses

file processing, and the file state changes from “WORK” to “PAUSE”. If pressed again, the system will continue

the paused processing file and the file state changes to “WORK”.

Emergency Switch: Stops file processing and cuts off the power supply of the driver, the LCD displays

“EMERGENCY STOP PLEASE RESET”. Turn the emergency switch clockwise to reset.

Press the “ORG” button to make the tip return to the zero point. After that, the emergency

switch can be run again.

4.2.4 File Processing Count And State

1. At the lower left corner of processing interface the processing times are displayed. Press “SHF” button to clear

the digit to 0.

2. At the lower right corner of processing interface, the file processing state is displayed. The processing state is

changing with the processing course. The file processing state shown in the table below:

Table 4-1: File Processing State

Work State

Remark

RESET

The system is resetting.

STOP

The process has been stopped.

WORK

Processing.

PAUSE

The process has been paused.

WAIT

Waiting time for hanging a work-piece during the loop-work process.

4.3 Off- Line Origin Calibration Interface

1. During the file processing, the deviation can be calibrated between the processing file and the real route by the

origin calibration.

2. At the file processing interface, press “ORG” button to go to the origin calibration interface.

X 033.3

Z 00000

Y 067.5

R 00000

Fig. 4-4: Origin Calibration Interface

X/Y/Z/R displays the tips current position. “MID” means the current processing speed is in the middle.

3. Orientation: the nozzle will move to the origin automatically when coming into the origin calibration interface.

4. Adjusting the tips position: After orientation, press the arrow buttons “  /  /  /  / Z / Z /

” to adjust the tips position.

5. Adjust the point’s speed: click the “SHF” button to change the point speed, MID-LOW-HI.

6. Calibration: after calibration, press “ENT” button to save the origin change and return to the file processing

interface. If press “ESC” button, it will not save the calibration result, and directly return file processing

interface.

4.4 Off- Line Loop-Work Parameter Setting Interface

1. In the loop-work parameters setting, the unit can start the process without an operator at the location.

2. Press the “LOOP” button at the processing interface and then enter into the “loop–work parameter setting

interface”.

SJ001 N=0000

T=000.0s Rn=0000

Fig.4-5: Loop–work Parameter Setting Interface

3. When setting, select the digit by moving the cursor under the digit. The arrow buttons “  ” & “  ” can

move the cursor left and right and the arrow buttons “  ” & “  ” can move the cursor up and down.

4. After completing adjust, press the “ENT” button to save the parameters and return to the file processing

interface. When the “N=0000” or “N=0001” is displayed, without loop work processing and the file only

processes one time.

4.5 Off-Line Testing Interface

Press the ESC button to enter into the the testing interface. In the testing interface, common system functions can

be tested if they are running correctly or not. The operating interface is as follows:

X 033.3

Z 00000

Y 067.5

R 00000

X 033.3

Z 08.2

Y 000.0

MID

Fig. 4-6: Testing Interface

4.6 Times of Nozzle Interface

At the testing interface, click the ESC button again and click the ESC button twice at the “Processing Interface”, it

comes into the “times of nozzle” interface (Fig.4-7). At “times of nozzle” interface, displays the times of nozzle has

been used and maximal limit times. The interface only can be viewed and cannot be set. Setting methods need refer

“teaching pendant”. “*****/*****”: The front digits mean the used times, the latter digits mean the maximal limit

times. When used times have reached the maximal limit times, the system will alarm and advise to change the

nozzle. If the latter digit is “00000”, this means that it does not limit the using times of nozzle.

Times of nozzle:

00000/00000

Fig. 4-7 Times of Nozzle Interface

N: Loop processing times set

T: Loop processing interval times set

Rn: Reset after loop N times

5. MOUNTING AND BRACKTRY

5.1 Tool Plate - Valve Mounting Bracket

5.2 Base Plate – Product Mounting Plate
