4 Installation of SIPLACE Pro and possible Setu p Types Installation manual SIPLACE Pro Edition 03/2005 US Version 3.0 26 After SIPLACE Pro has successfu lly checked the user acco unt and it s administrator right s, the …

Installation manual SIPLACE Pro 4 Installation of SIPLACE Pro and possible Setup Types

Version 3.0 Edition 03/2005 US

Step 3

The "Configuration of SIPLACE Pro Server" dialog box specifies which Windows user account the

server component of SIPLACE Pro should run under. The current domain appears as the default

value in the account text box. This means it is usually sufficient just to add the account name. How-

ever, if this account is local, be sure to change this field appropriately. 4

Fig. 4 - 11 "Configuration of SIPLACE Pro" dialog box

Æ Enter the Account and Password for the Windows user in the dialog box.

Æ For new installations and upgrades, the option Access rights is deactivated by default. This

means there is no restriction of access rights on stored objects. We recommend you leave this

deactivated until you have created Users, Groups and set Privileges & Permissions in

SIPLACE Pro.

Æ The use of Support of X-Series is activated by default. This means that X-Series cameras and

nozzles can be automatically assigned when new Component Shapes are created.

Hint

Make sure that the properties for the user account are set to "Password never expires". Otherwise,

as soon as the password has expired, the system will not be operable until the COM+ package

SIPLACE Pro has been reconfigured. This can be done using the script COM+ServerAdmin.vbs,

which is located in the Start Menu (Start -->Programs --> Siemens SIPLACE -->Administration

--> COM+Server Administration). For more details please contact your system administrator. 4

4 Installation of SIPLACE Pro and possible Setup Types Installation manual SIPLACE Pro

Edition 03/2005 US Version 3.0

After SIPLACE Pro has successfully checked the user account and its administrator rights, the

SQL Server window opens. 4

Step 4

In the "Select SQL-Server" dialog box you enter the information required to be connected with the

SQL Server and database. 4

Fig. 4 - 12 "Select SQL-Server" dialog box

Æ Enter the "Password for the SQL Server user "sa", i.e. the SQL server system administrator.

Note

This password is empty if MSDE has been freshly installed. In this case, click on Next. Subse-

quently, a window will open, prompting you to change this password. You may accept the Siemens

Service default password or choose one of your own. 4

Æ Choose your SQL Server Instance from the drop-down menu.

Æ Click Next.

Installation manual SIPLACE Pro 4 Installation of SIPLACE Pro and possible Setup Types

Version 3.0 Edition 03/2005 US

In case no database with the name "SIPLACE Pro" exists, the following dialog will appear: 4

Fig. 4 - 13 "Create database" dialog box

Æ If you choose Select another SQL Server instance you will be returned to the previous

dialog.

Æ Click Next to create a new database.

Fig. 4 - 14 "Database initialization" dialog box
