Installation manual SIPLACE Pro 7 Uninstalling
Version 3.0 Edition 03/2005 US
51
7 Uninstalling
7.1 Uninstalling the software
Uninstalling SIPLACE Pro deletes all SIPLACE Pro software components from the system except
for the SIPLACE Pro Database. 7
The SIPLACE Pro Database is not automatically uninstalled in order to prevent possible data
loss. 7
Step 1
Uninstall SIPLACE Pro via the Control Panel. 7
You require the uninstall window in Windows for uninstalling. 7
Æ Click Start in the Windows start menu.
Æ Click Settings.
Æ Click Control Panel.
Æ Double-click Add / Remove Programs.
A list appears with the names of the software packages installed on the computer. 7
Æ Select SIPLACE Pro.
Æ Click the Change/Remove components button.
Æ In the "Confirm File Deletion" dialog box, click Yes if you wish to proceed or No if you wish to
cancel the uninstall process.
Æ Select Remove to remove all installed features.
Æ Click Next to continue.
Æ In the "Confirm File Deletion" dialog box, click OK if you wish to proceed or Cancel if you wish
to cancel the uninstall process.
Æ In the license dialog box you could choose if you want to keep the license on this computer for
future installations or if you want to remove the license from this computer.
Æ Click Next and you get a summary of all components to be deleted.
Æ Click Next if you accept all the information entered so far.
Æ Click Done.
7 Uninstalling Installation manual SIPLACE Pro
Edition 03/2005 US Version 3.0
52
Step 2
Clean up the registry. 7
Æ Go to the "registry editor"
via Start - Run - then type in "regedit".
Æ Select HKEY_LOCAL_MACHINE\SOFTWARE\Siemens SIPLACE
Æ Delete the following entries:
Line Control GUI 2.0
LineControlServer 1.0
SIPLACE Pro 1.0
SIPLACE Pro 2.0
SIPLACE Pro SetupLog
Step 3
Clean up the disk and make sure that there are no more program files. 7
Æ Check the path Program Files\Siemens SIPLACE\SIPLACE Pro.
Æ If you will find additional files, please delete them (except for the database).
7.2 Uninstalling the database
7.2.1 On SQL Server 2000 installations
Warning
All data for SIPLACE Pro will be deleted. This step is only for database administrators. 7
Æ Go to "Microsoft SQL Server - Enterprise Manager".
Æ Select the database "SIPLACEPro".
Æ With the right-mouse button select "delete".
All database files of SIPLACE Pro will be deleted. 7
7.2.2 On MSDE installations
Æ Uninstall the MSDE instance used for SIPLACE Pro.
Æ Remove the database files.
7
Installation manual SIPLACE Pro 8 Connecting SIPLACE Pro to the Unix Line Computer
Version 3.0 Edition 03/2005 US
53
8 Connecting SIPLACE Pro to the Unix Line
Computer
8.9 General information
The line computer and SIPLACE Pro must be configured in a common network to enable line com-
puter data to be exchanged with SIPLACE Pro. SIPLACE Pro runs under the Windows operating
system, whereas the line computers run on a UNIX platform. Certain preparations must be made
to enable both computers to communicate with one another. 8
Siemens recommends installing Samba on the UNIX line computer to enable SIPLACE Pro to ac-
cess the UNIX line computer. 8
Once Samba has been installed on the UNIX line computer, it is possible to establish a network
connection between the UNIX environment (NFS) and Windows (NTFS), and data can be ex-
changed. 8
8.10 Installing Samba on the UNIX Line Computer
A UNIX diskette or a CD ROM containing the archived Samba software is required for installing
Samba. 8
For the purposes of this description, it is assumed that the operating system and the line computer
software have been installed on the computer and they are functioning correctly. The following
steps can then be performed: 8
Æ With the line computer software running, use the mouse to select the Options menu command
from the main menu.
Æ Select Install Options.
A window appears in which the user is prompted to insert the diskette. 8
Æ Insert the disk and confirm by clicking on Enter.
This starts the installation of »Samba«. 8
8.10.1 Line Computer with the SCO ODT 3.0 operating system
Æ Insert the appropriate diskette for the operating system.
The installation routine is automatic; the user does not have to intervene.
Æ After installation, reboot your computer to use »Samba«.
