6 User Manual SIPLACE Linear Dipping Unit 2 X 05/2020
Contents
1 Introduction
1.1 Module Description
User Manual SIPLACE Linear Dipping Unit 2 X 05/2020 7
1 Introduction
This user manual contains technical information and descriptions to operate the SIPLACE Linear
Dipping Unit 2 X (LDU 2 X).
1.1 Module Description
The LDU2X is a special feeder module that makes flux available in a pre-defined layer thickness.
Components can be dipped into the flux to improve their solderability. The LDU2X is set up on a
changeover table in the same way as any other X-feeder module and is controlled by the station
software and SIPLACE Pro (line software).
The LDU 2 X can be ordered in a special version, which provides the possibility to use a special
dipping plate with an adjustable cavity depth. This option allows a more flexible operation and also
may reduce the number of LDU 2 X units if multiple cavity depths are needed in one placement
task.
NOTICE
It is not possible to retrofit an Auto Cavity option to a standard LDU 2 X.
1.1.1 EU Declaration of Conformity
The products/devices described below conform to the regulations and standards listed in the EU
Declaration of Conformity provided.
Type: SIPLACE Linear Dipping Unit 2 X
Item no.: 00117012-xx
Type: SIPLACE Linear Dipping Unit 2 X Auto Cavity
Item no.: 00117018-xx
Manufacturer:
ASM Assembly Systems GmbH & Co.KG
Rupert-Mayer-Str. 44
81379 Munich
Germany
1.1.2 Correct Usage
The product may only be used for the application described in the catalogues and technical spe-
cifications i.e. for placement of SMD components and only in connection with the third party
devices and components recommended or approved by ASM Assembly Systems GmbH & Co. KG.
Any other use is deemed to be incorrect and not as prescribed.
In the case of incorrect usage, ASMAssembly SystemsGmbH&Co.KG will not assume liability
for any damage which occurs and will not guarantee the correct and proper function of machine
components.
Prescribed or correct usage includes the observance of all the instructions in the user manual.
The proper and safe operation of the product requires correct transportation, storage, installation
and assembly, plus careful, accurate utilization and servicing.
1.1.3 Incorrect Usage
Failure to use the product as prescribed can result in both danger to life and limb and material
damage. For this reason, non-prescribed usage is prohibited. If the product is not used as pre-
scribed, ASM Assembly Systems GmbH & Co. KG will not accept liability for any damage that may
occur and will not guarantee that the components will work properly and without problems.
Non-prescribed usage of the product includes the following examples:
●
Operation of the product with safety equipment deactivated or removed
●
Use of components that do not meet the permitted specification
1 Introduction
1.1 Module Description
8 User Manual SIPLACE Linear Dipping Unit 2 X 05/2020
●
Use of unauthorized accessories and additional modules
●
Use of the placement machine by unqualified personnel
1.1.4 Requirements and restrictions
●
The LDU 2 X can be used on all placement machines with an X-table.
●
A maximum number of 2 LDU2X can be set up on an X-table.
●
The LDU 2 X can be used with all placement heads.
●
For operating the LDU 2 X, station software version 711.0 or higher and SIPLACE Pro version
15.0 or higher are required.
●
The LDU 2 X can handle component sizes from 0.2mm x 0.2mm up to 42mmx42mm.
When using a placement machine X4i with a WPC (waffle pack changer) the maximum
component size is reduced to 32mmx32mm.
●
The LDU 2 X with Auto Cavity option can handle component sizes from 0.2mmx0.2mm up
to 15mmx25mm.
●
Using the LDU 2 X in the placement process reduces the placement rate of a machine.
●
The LDU 2 X can be operated outside the machine with the help of an SSE (Single Slot
EDIF). In this operation mode some functions, e.g. removing and fitting parts, are not avail-
able.
●
When dipping components, no placement data are generated for the Operator Information
System (OIS).
1.1.5 Technical data
SIPLACE Linear Dipping Unit 2 X
Dimensions (L x W x H) 629mm x 105mm x 202mm
Weight 11kg
Power consumption 24VDC – 30VDC, 2A (60W)
Max. noise emission 61 dB (A)
Temperature range (storage) from -25 °C to +55 °C
Temperature range (operation) from +15 °C to +35 °C
Atmospheric humidity (storage) ≤ 95%
Atmospheric humidity (operation) 30% - 75% (on average not exceeding 45%)
1.1.6 Environmentally-friendly disposal of materials and components
SIPLACE products are manufactured using only materials and parts that can be easily separated
and disposed of in an environmentally-friendly way.
NOTICE
Observe the applicable regulations
The company operating the system has sole responsibility for the proper, environmentally-
friendly disposal of machines, working materials, consumable materials and wear parts.
► Please observe your national statutory provisions for waste disposal and environ-
mental protection.
1.1.7 Electromagnetic compatibility (EMC)
All SIPLACE products are designed and tested for professional use in industrial applications. Elec-
tromagnetic compatibility in terms of the emission of interference cannot be guaranteed in any
other environment.
