elcometer.com 11 Dry Film Thickness - Digital Elcometer 456 Angled Probes Probe Range for Separate Coating Thickness Gauge Elcometer 456 Choosing the correct probe for your coating thickness gauge: Take readings in areas…

100%1 / 32
10
Dry Film Thickness - Digital
Scan Probes
Straight Probes
Probe Range for Separate Coating Thickness GaugeElcometer 456
Choosing the correct probe for your coating thickness gauge:
Standard probes measure
coatings on both at and
curved surfaces.
Standard Straight Probe
Mini probes are ideal for
harder to reach areas
and edges.
Mini Probe
Large surface area
probes are for soft
materials (HVCA
approved).
Soft Coating Probe
Chemical resistant &
washable - ideal for the
anodising environment.
Anodising Probe
Sealed for use
underwater at depth,
even in diving gloves.
Waterproof Probe
Ideal for measuring
coatings up to 31mm
thick.
Thick Coatings Probe
Rapidly scan large
surface areas without
damaging the probe or
the coating.
Standard Scan Probe
Clip on adaptors for
large coated structures,
abrasive coatings and
pre-construction primers.
Ball Bearing Scan Probe
1
1
UK Patent Number: 2571577
elcometer.com
11
Dry Film Thickness - Digital
Elcometer 456
Angled Probes
Probe Range for Separate Coating Thickness GaugeElcometer 456
Choosing the correct probe for your coating thickness gauge:
Take readings in areas
with restricted clearance.
Right Angle Probe
Extending probes for hard
to reach areas.
Telescopic Probe
For measuring coatings
on edges, narrow pipes
or small surface areas.
Mini Right Angle Probe
Measure difcult to
access or complex
areas.
45° Angle Probe
Plug In Integral Probes (PINIP™)
Transforms a separate
gauge into an integral
gauge, ideal for single
handed use.
PINIP™ Integral Probe
Measure coatings on
ferrous substrates up to
250°C (480°F).
Hi-Temperature PINIP™
Armoured Cable Probes
Reinforced heavy duty cables reduce the risk of cable damage.
F / FNF Armoured Probe
12
Dry Film Thickness - Digital
Accuracy
a
: ±1-3% or ±2.5μm ±1-3% or ±0.1mil
Range: 0-500μm 0-20mils
Resolution:
0.1μm: 0-100μm
1μm: 100-500μm
0.01mil: 0-5mils
0.1mil: 5-20mils
Certicate: ●
1
2
3
4
5
6
7
8
Scale 0.5 Probe Range 0-500μm / 0-20mils
Probe Range for Separate Coating Thickness GaugeElcometer 456
See '#' on the probes table on the opposite page for comparison.
c. Probe length is measured from X to Y
d. for Elcometer 456 Model T gauges only
Elcometer 456 probes are covered by a 1 year warranty
a. Whichever is the greater
b. FNF (F): FNF probe in F Mode FNF (N): FNF probe in N Mode
● Certicate supplied as standard.
X Y
