6 Dry Film Thickness - Digital Model B Model S Model T Fast, accurate reading rate; 70+ readings per minute ■ ■ ■ Repeatable & reproducible measurements ■ ■ ■ Easy to use menu structure; in 30+ languages ■ ■ ■ T ough…

elcometer.com

Dry Film Thickness - Digital

When tested on smooth surfaces probe end caps have been scanned in excess of 50km (30 miles)

Scan Probes

The Scan Probes further enhance the speed and accuracy of eld based dry

lm coating thickness measurement:

• Featuring a highly durable ‘snap on’ replaceable probe cap

• A revolutionary design which allows users to take individual readings or

rapidly scan large surface areas - without damaging the probe or coating

• Any cap wear during use

is incorporated within the calibration process -

the gauge even informs the user when to replace the cap.

• Standard Scan Probe or larger Roller Bearing Scan Probe available

• Roller Bearing Scan Probe is ideal for large coated structures, abrasive

coatings and pre-construction primers.

Counted Average and Fixed Batch Modes

Counted Average Mode

• The Elcometer 456 Model S and Model T are supplied with the Counted

Average Mode

• Once the user has dened the number of individual gauge readings to be

taken within a spot measurement, the gauge stores the average of the

individual gauge readings into the memory.

Working with Standards and Test Methods

• International Standards and test methods often describe the number of

individual gauge readings to be taken in a spot measurement and/or the

number of spot measurements required over a dened surface area.

• SSPC PA2 requires a minimum of three gauge readings to be taken per

spot measurement and ve spot measurements over 10m

(~100ft

• The Elcometer 456 Model S or Model T can be set with a counted average

of three and a xed batch size of ve to meet these requirements. Each

batch denes an area of measurement.

• When the Scan Probe is connected to the Elcometer 456 Model T with

Auto Repeat Mode selected, SSPC PA2 (or similar test methods) can be

completed more than 40% faster.

Fixed Batch Sizes

• The Fixed Batch Size feature within the Elcometer 456 Model T allows

users to dene the maximum number of readings in each batch.

• Once the maximum number of readings has been reached the gauge automatically opens up a new batch

which is linked to the previous batch (name-1, name-2, etc.).

Separate Coating Thickness GaugeElcometer 456

Dry Film Thickness - Digital

Model B Model S Model T

Fast, accurate reading rate; 70+ readings per minute

■ ■ ■

Repeatable & reproducible measurements

■ ■ ■

Easy to use menu structure; in 30+ languages

■ ■ ■

Tough, impact, waterproof & dust resistant; equivalent to IP64

■ ■ ■

Bright colour screen; with permanent backlight

■ ■ ■

Scratch & solvent resistant display; 2.4” (6cm) TFT

■ ■ ■

Large positive feedback buttons

■ ■ ■

USB power supply; via PC

■ ■ ■

Test certicate

■ ■ ■

2 year gauge warranty

■ ■ ■

Automatic rotating display; 0°, 90°, 180° & 270°

■ ■ ■

Ambient light sensor; with adjustable auto brightness

■ ■ ■

Emergency light

■ ■ ■

Tap awake from sleep

■ ■ ■

Gauge software updates

; via ElcoMaster

software

■ ■ ■

Data output

■ ■ ■

USB; to computer

■ ■ ■

Bluetooth

; to computer, Android

™

& iOS

devices

■ ■

On screen statistics

■ ■ ■

Number of readings; η Mean (average); x Standard deviation; σ

Highest reading; Hi Lowest reading; Lo Coe󰀩cient of variation; CV%,

Elcometer index value

; EIV

■ ■ ■

Nominal dry lm thickness; NDFT

■ ■

IMO PSPC; %>NDFT, %>90<NDFT, 90:10 pass/fail

■ ■

High & low limits; denable audible & visual alarms

■ ■

Number of readings above high limit;

■ ■

Number of readings below low limit;

■ ■

Live reading trend graph; in Batch Mode

■ ■

ElcoMaster

software & USB cable

□ ■ ■

Replaceable screen protectors

□ ■ ■

Protective case

■ ■ ■

Plastic transit case

□ □ ■

Separate models; with automatic probe recognition

■ ■ ■

Probe type; Ferrous (F), Non-Ferrous (N), Dual (FNF)

F, N, FNF F, N, FNF F, N, FNF

Measurement range; see page 7-12 for probe selection

0-31mm

0-1,220mils

0-31mm

0-1,220mils

0-31mm

0-1,220mils

On screen calibration instructions; in 30+ languages ■ ■ ■

Multiple calibration methods ■ ■ ■

Factory; resets to the factory calibration ■ ■ ■

2-point; for smooth and rough surfaces ■ ■ ■

1-point; zero calibration ■ ■ ■

Zero o󰀨set; for calibration according to ISO19840 ■ ■

Predened calibration & measurement methods ■ ■

ISO, SSPC PA2, Swedish, Australian ■ ■

The Elcometer 456 is supplied with a 1 year warranty against manufacturing defects. The warranty can be extended free of charge to 2 years within 60 days of purchase via

www.elcometer.com.

Internet connection required

Visit www.elcometer.com/sdk to find out how to integrate Elcometer’s MFi certified products to your App.

Elcometer Index Values are used in the automotive industry to assess a coating’s overall quality; USA Patent Number US7606671B2

Separate Coating Thickness GaugeElcometer 456

Product Features

■ Standard □ Optional

elcometer.com

Dry Film Thickness - Digital

Model B Model S Model T

Automatic calibration; for rapid calibration

■ ■

Calibration memory type; gauge (g) or gauge & batch (gb)

g gb gb

Number of batches; with unique calibrations

1 2,500

Calibration memories; 3 user-programmable memories

■

Measurement outside calibration warning

■

Calibration lock; with optional PIN code unlock

■ ■ ■

Delete last reading

■ ■ ■

Gauge memory; number of readings

Last 5 1,500 150,000

Individual batch calibrations; sent to PC via ElcoMaster

software

■ ■

Limits; user definable audible & visual pass/fail warnings

■ ■

Gauge (g) or gauge & batch specic (gb) limits

g gb

Date and time stamp

■ ■

Review, clear & delete batches

■ ■

Batch types; normal, counted average, IMO PSPC

■ ■

Navsea Mode

■

Batch review graph

■

Copy batches and calibration settings

■

Alpha-numeric batch names; user denable on the gauge

■

Scan & Auto Repeat Modes; with Scan Probe connected

■

Fixed Batch Size Mode; with batch linking

■

Model Model B Model S Model T Certicate

Elcometer 456 Ferrous Separate A456CFBS A456CFSS A456CFTS ●

Elcometer 456 Non-Ferrous Separate A456CNBS A456CNSS A456CNTS ●

Elcometer 456 Dual FNF Separate A456CFNFBS A456CFNFSS A456CFNFTS ●

Display Information 2.4” (6cm) QVGA colour TFT display, 320 x 240 pixels

Battery Type 2 x AA batteries, rechargeable batteries can also be used

Battery Life approximately 24 hours of continuous use at 1 reading per second*

Gauge Dimensions (h x w x d) 141 x 73 x 37mm (5.55 x 2.87 x 1.46”)

Gauge Weight (including batteries supplied) 161g (5.68oz)

Operating Temperature -10 to 50°C (14 to 122°F)

Packing List Elcometer 456 gauge, wrist harness, transit case (T),

protective case (B, S, T), 1 x screen protector (S, T), 2 x AA batteries,

operating instructions, USB cable (S, T), ElcoMaster

software (S, T)

For separate gauge probe options see page 7-12

*** Using default settings & lithium batteries, alkaline or rechargeable batteries may di󰀨er

● Certicate supplied as standard

STANDARDS:

AS 2331.1.4, AS 3894.3-B, AS/NZS 1580.108.1, ASTM B244, ASTM B 499, ASTM D 1186-B, ASTM D 1400, ASTM D 7091, ASTM E 376, ASTM G 12,

BS 3900-C5-6B, BS 3900-C5-6A, BS 5411-11, BS 5411-3, BS 5599, DIN 50981, DIN 50984, ECCA T1, EN 13523-1, IMO MSC.215(82),

IMO MSC.244 (83), ISO 1461, ISO 19840, ISO 2063, ISO 2178, ISO 2360, ISO 2808-6A, ISO 2808-6B, ISO 2808-7C, ISO 2808-7D, ISO 2808-12,

JIS K 5600-1-7, NF T30-124, SS 184159, SSPC PA 2, US Navy PPI 63101-000, US Navy NSI 009-32

Separate Coating Thickness GaugeElcometer 456

Product Features

■ Standard □ Optional

Technical Specication
