elcometer.com 7 Dry Film Thickness - Digital Model B Model S Model T Automatic calibration; for rapid calibration ■ ■ Calibration memory type; gauge (g) or gauge & batch (gb) g gb gb Number of batches; with unique ca…

100%1 / 32
6
Dry Film Thickness - Digital
Model B Model S Model T
Fast, accurate reading rate; 70+ readings per minute
■ ■ ■
Repeatable & reproducible measurements
■ ■ ■
Easy to use menu structure; in 30+ languages
■ ■ ■
Tough, impact, waterproof & dust resistant; equivalent to IP64
■ ■ ■
Bright colour screen; with permanent backlight
■ ■ ■
Scratch & solvent resistant display; 2.4” (6cm) TFT
■ ■ ■
Large positive feedback buttons
■ ■ ■
USB power supply; via PC
■ ■ ■
Test certicate
■ ■ ■
2 year gauge warranty
1
■ ■ ■
Automatic rotating display; 0°, 90°, 180° & 270°
■ ■ ■
Ambient light sensor; with adjustable auto brightness
■ ■ ■
Emergency light
■ ■ ■
Tap awake from sleep
■ ■ ■
Gauge software updates
2
; via ElcoMaster
®
software
■ ■ ■
Data output
■ ■ ■
USB; to computer
■ ■ ■
Bluetooth
®
; to computer, Android
™
& iOS
3
devices
■ ■
On screen statistics
■ ■ ■
Number of readings; η Mean (average); x Standard deviation; σ
Highest reading; Hi Lowest reading; Lo Coe󰀩cient of variation; CV%,
Elcometer index value
4
; EIV
■ ■ ■
Nominal dry lm thickness; NDFT
■ ■
IMO PSPC; %>NDFT, %>90<NDFT, 90:10 pass/fail
■ ■
High & low limits; denable audible & visual alarms
■ ■
Number of readings above high limit;
■ ■
Number of readings below low limit;
■ ■
Live reading trend graph; in Batch Mode
■ ■
ElcoMaster
®
software & USB cable
□ ■ ■
Replaceable screen protectors
□ ■ ■
Protective case
■ ■ ■
Plastic transit case
□ □ ■
Separate models; with automatic probe recognition
■ ■ ■
Probe type; Ferrous (F), Non-Ferrous (N), Dual (FNF)
F, N, FNF F, N, FNF F, N, FNF
Measurement range; see page 7-12 for probe selection
0-31mm
0-1,220mils
0-31mm
0-1,220mils
0-31mm
0-1,220mils
On screen calibration instructions; in 30+ languages ■ ■ ■
Multiple calibration methods ■ ■ ■
Factory; resets to the factory calibration ■ ■ ■
2-point; for smooth and rough surfaces ■ ■ ■
1-point; zero calibration ■ ■ ■
Zero o󰀨set; for calibration according to ISO19840 ■ ■
Predened calibration & measurement methods ■ ■
ISO, SSPC PA2, Swedish, Australian ■ ■
1
The Elcometer 456 is supplied with a 1 year warranty against manufacturing defects. The warranty can be extended free of charge to 2 years within 60 days of purchase via
www.elcometer.com.
2
Internet connection required
3
Visit www.elcometer.com/sdk to find out how to integrate Elcometer’s MFi certified products to your App.
4
Elcometer Index Values are used in the automotive industry to assess a coating’s overall quality; USA Patent Number US7606671B2
Separate Coating Thickness GaugeElcometer 456
Product Features
■ Standard □ Optional
elcometer.com
7
Dry Film Thickness - Digital
Model B Model S Model T
Automatic calibration; for rapid calibration
■ ■
Calibration memory type; gauge (g) or gauge & batch (gb)
g gb gb
Number of batches; with unique calibrations
1 2,500
Calibration memories; 3 user-programmable memories
■
Measurement outside calibration warning
■
Calibration lock; with optional PIN code unlock
■ ■ ■
Delete last reading
■ ■ ■
Gauge memory; number of readings
Last 5 1,500 150,000
Individual batch calibrations; sent to PC via ElcoMaster
®
software
■ ■
Limits; user definable audible & visual pass/fail warnings
■ ■
Gauge (g) or gauge & batch specic (gb) limits
g gb
Date and time stamp
■ ■
Review, clear & delete batches
■ ■
Batch types; normal, counted average, IMO PSPC
■ ■
Navsea Mode
■
Batch review graph
■
Copy batches and calibration settings
■
Alpha-numeric batch names; user denable on the gauge
■
Scan & Auto Repeat Modes; with Scan Probe connected
■
Fixed Batch Size Mode; with batch linking
■
Model Model B Model S Model T Certicate
Elcometer 456 Ferrous Separate A456CFBS A456CFSS A456CFTS ●
Elcometer 456 Non-Ferrous Separate A456CNBS A456CNSS A456CNTS ●
Elcometer 456 Dual FNF Separate A456CFNFBS A456CFNFSS A456CFNFTS ●
Display Information 2.4” (6cm) QVGA colour TFT display, 320 x 240 pixels
Battery Type 2 x AA batteries, rechargeable batteries can also be used
Battery Life approximately 24 hours of continuous use at 1 reading per second*
Gauge Dimensions (h x w x d) 141 x 73 x 37mm (5.55 x 2.87 x 1.46”)
Gauge Weight (including batteries supplied) 161g (5.68oz)
Operating Temperature -10 to 50°C (14 to 122°F)
Packing List Elcometer 456 gauge, wrist harness, transit case (T),
protective case (B, S, T), 1 x screen protector (S, T), 2 x AA batteries,
operating instructions, USB cable (S, T), ElcoMaster
®
software (S, T)
For separate gauge probe options see page 7-12
*** Using default settings & lithium batteries, alkaline or rechargeable batteries may di󰀨er
● Certicate supplied as standard
STANDARDS:
AS 2331.1.4, AS 3894.3-B, AS/NZS 1580.108.1, ASTM B244, ASTM B 499, ASTM D 1186-B, ASTM D 1400, ASTM D 7091, ASTM E 376, ASTM G 12,
BS 3900-C5-6B, BS 3900-C5-6A, BS 5411-11, BS 5411-3, BS 5599, DIN 50981, DIN 50984, ECCA T1, EN 13523-1, IMO MSC.215(82),
IMO MSC.244 (83), ISO 1461, ISO 19840, ISO 2063, ISO 2178, ISO 2360, ISO 2808-6A, ISO 2808-6B, ISO 2808-7C, ISO 2808-7D, ISO 2808-12,
JIS K 5600-1-7, NF T30-124, SS 184159, SSPC PA 2, US Navy PPI 63101-000, US Navy NSI 009-32
Separate Coating Thickness GaugeElcometer 456
Product Features
■ Standard □ Optional
Technical Specication
8
Dry Film Thickness - Digital
Probe Range for Separate Coating Thickness GaugeElcometer 456
All Elcometer 456 probes are fully interchangeable and are
available in a number of designs and scale ranges to meet your
specic application, including;
All Elcometer 456 probes are available in a number of designs
and scale ranges to meet your specic application.
Supplied with a Test
Certicate and a set of
calibration foils
Ferrous, non-ferrous and
dual FNF probes available
Fully interchangeable and
available in a number of
designs and scale ranges
Ergonomic design, ideal
for continuous use
Temperature stable
measurements
