24
Dry Film Thickness - Digital
Integral Coating Thickness GaugeElcometer 456
Easy to read, user
denable display with
automatic screen
brightness
Reading rate of
70+ per minute
Scratch and solvent
resistant screen
Ergonomic design,
ideal for continuous
use
Bigfoot
™
integral probe
Stores up to
150,000 readings in
alphanumeric batches
Measure coatings up
to 13mm (500mils)
on metal substrates
The Elcometer 456 Coating Thickness Gauge is available with an
integral probe; ideal for single handed operation for consistent,
repeatable and accurate results.
Elcometer 3045
·
F
A
S
T
·
R
E
P
E
A
T
A
B
L
E
·
A
C
C
U
R
A
T
E
·
D
U
R
A
B
L
E
Measure
DFT
Ferrous & Non-Ferrous Substrates
wireless technology
compatible with
ElcoMaster
®
®
video available
tv
elcometer.tv
elcometer.com
25
Dry Film Thickness - Digital
elcometer.com/videos
Elcometer 3045
·
F
A
S
T
·
R
E
P
E
A
T
A
B
L
E
·
A
C
C
U
R
A
T
E
·
D
U
R
A
B
L
E
Measure
DFT
Ferrous & Non-Ferrous Substrates
Calibrated and ready for immediate use
Easy to use menus, large buttons and colour LCD screen with auto rotate;
factory calibrated and ready to use, straight from the box.
Accurate measurements on smooth, rough, thin and
curved surfaces
With a thickness measurement capability to ±1% and increased reading
resolution, the Elcometer 456 produces accurate, temperature stable
measurements every time.
Peace of mind
Repeatable and reproducible and available with a 2 year
1
manufacturer’s
warranty; giving you peace of mind.
Durable and suitable for use in harsh environments
Suitable for use in harsh environments, the Elcometer 456 is sealed, heavy duty
and impact resistant with dust and waterproof equivalent to IP64.
Accurate
Reliable
Rugged
Easy
Store up to 150,000 readings in 2,500 batches
Measures up to 13mm (500mils) of coating on metal substrates with USB and
Bluetooth
®
data output making it compatible with ElcoMaster
®
software.
Powerful
STANDARDS:
AS 2331.1.4, AS 3894.3-B, AS/NZS 1580.108.1, ASTM B244, ASTM B 499, ASTM D 1186-B, ASTM D 1400, ASTM D 7091, ASTM E 376, ASTM G 12,
BS 3900-C5-6B, BS 3900-C5-6A, BS 5411-11, BS 5411-3, BS 5599, DIN 50981, DIN 50984, ECCA T1, EN 13523-1, IMO MSC.215(82),
IMO MSC.244 (83), ISO 1461, ISO 19840, ISO 2063, ISO 2178, ISO 2360, ISO 2808-6A, ISO 2808-6B, ISO 2808-7C, ISO 2808-7D, ISO 2808-12,
JIS K 5600-1-7, NF T30-124, SS 184159, SSPC PA 2, US Navy PPI 63101-000, US Navy NSI 009-32
1
The Elcometer 456 is supplied with a 1 year warranty against manufacturing defects.
2
Compatible with iPod, iPhone and iPad.
The warranty can be extended free of charge to 2 years within 60 days of purchase via www.elcometer.com.
Integral Coating Thickness GaugeElcometer 456
Easy to use and minimum
set up required
USB and Bluetooth
®
data output to
iPhone
2
or Android
™
devices
Bigfoot™ integral probe
for accurate measurements
Large easy to read measurements in
Metric and Imperial units
26
Dry Film Thickness - Digital
Integral Coating Thickness GaugeElcometer 456
Model B Model S Model T
Fast, accurate reading rate; 70+ readings per minute
■ ■ ■
Repeatable & reproducible measurements
■ ■ ■
Easy to use menu structure; in 30+ languages
■ ■ ■
Tough, impact, waterproof & dust resistant; equivalent to IP64
■ ■ ■
Bright colour screen; with permanent backlight
■ ■ ■
Scratch & solvent resistant display; 2.4” (6cm) TFT
■ ■ ■
Large positive feedback buttons
■ ■ ■
USB power supply; via PC
■ ■ ■
Test certicate
■ ■ ■
2 year gauge warranty
1
■ ■ ■
Automatic rotating display; 0°, 90°, 180° & 270°
■ ■ ■
Ambient light sensor; with adjustable auto brightness
■ ■ ■
Emergency light
■ ■ ■
Tap awake from sleep
■ ■ ■
Gauge software updates
2
; via ElcoMaster
®
software
■ ■ ■
Data output
■ ■ ■
USB; to computer
■ ■ ■
Bluetooth
®
; to computer, Android
™
& iOS
3
devices
■ ■
On screen statistics
■ ■ ■
Number of readings; η, Mean (average); x, Standard deviation; σ
Highest reading; Hi, Lowest reading; Lo, Coe󰀩cient of variation;
CV%, Elcometer index value
4
; EIV
■ ■ ■
Nominal dry lm thickness; NDFT
■ ■
IMO PSPC; %>NDFT, %>90<NDFT, 90:10 pass/fail
■ ■
High & low limits; denable audible & visual alarms
■ ■
Number of readings above high limit;
■ ■
Number of readings below low limit;
■ ■
Live reading trend graph; in Batch Mode
■ ■
ElcoMaster
®
software & USB cable
□ ■ ■
Replaceable screen protectors
□ ■ ■
Protective case
■ ■ ■
Plastic transit case
□ □ ■
Integral models; with automatic gauge switch on
■ ■ ■
Probe type; Ferrous (F), Non-Ferrous (N), Dual (FNF)
F, N, FNF F, N, FNF F, N, FNF
Measurement range
0-13mm
0-500mils
0-1500μm
0-60mils
0-1500μm
0-60mils
On screen calibration instructions; in 30+ languages
Multiple calibration methods ■ ■ ■
Factory; resets to the factory calibration ■ ■ ■
2-point; for smooth and rough surfaces ■ ■ ■
1-point; zero calibration ■ ■ ■
Zero o󰀨set; for calibration according to ISO19840 ■ ■
Predened calibration & measurement methods ■ ■
ISO, SSPC PA2, Swedish, Australian ■ ■
1
The Elcometer 456 is supplied with a 1 year warranty against manufacturing defects. The warranty can be extended free of charge to 2 years within 60 days of purchase via
www.elcometer.com. Elcometer 456 probes are covered by a 1 year warranty.
2
Internet connection required
3
Visit www.elcometer.com/sdk to nd out how to integrate Elcometer’s MFi certied products to your App.
4
Elcometer Index Values are used in the automotive industry to assess a coating’s overall quality; USA Patent Number US7606671B2
Product Features
■ Standard □ Optional
