elcometer.com 3 Dry Film Thickness - Digital elcometer.com/videos For a wide range of probes to meet your specic application, see page 8 * The Elcometer 456 is supplied with a 1 year warranty against manufacturing defec…
2
Dry Film Thickness - Digital
Ergonomic design,
ideal for continuous use
Dust and waterproof rugged
design equivalent to IP64
Easy to read, user denable
display with automatic screen
brightness
Measure coatings up to
31mm (1,220mils) on
metal substrates
Temperature stable
measurements
The Elcometer 456 coating thickness gauge is available with a
wide range of interchangeable probes; providing greater coating
thickness measurement exibility on metal substrates.
Separate Coating Thickness GaugeElcometer 456
Elcometer 3045
·
F
A
S
T
·
R
E
P
E
A
T
A
B
L
E
·
A
C
C
U
R
A
T
E
·
D
U
R
A
B
L
E
Measure
DFT
Ferrous & Non-Ferrous Substrates
wireless technology
compatible with
ElcoMaster
®
®
video available
tv
elcometer.tv
elcometer.com
3
Dry Film Thickness - Digital
elcometer.com/videos
For a wide range of probes to meet your specic application,
see page 8
* The Elcometer 456 is supplied with a 1 year warranty against manufacturing defects. The warranty can be extended free of charge to 2 years within 60 days of purchase
via www.elcometer.com.
Elcometer 3045
·
F
A
S
T
·
R
E
P
E
A
T
A
B
L
E
·
A
C
C
U
R
A
T
E
·
D
U
R
A
B
L
E
Measure
DFT
Ferrous & Non-Ferrous Substrates
Elcometer 456 Separate Coating Thickness Gauge
Helping you become more efcient
70+ readings per minute and 140+ per minute with Scan Probe, multiple
calibration memories and alphanumeric batch identication.
Accurate measurements on smooth, rough, thin and
curved surfaces
Measures on smooth, rough, thin and curved surfaces to ±3% or 2.5µm, in
accordance with National & International Standards.
Large buttons and colour screen
LCD screen with auto rotate; factory calibrated with high and low reading limit
indicators in multiple languages.
Designed to last
Heavy duty, impact resistant and supplied with fully traceable test certicates
and our 2 year gauge warranty*.
Accurate
Easy
Reliable
Fast
Powerful
Store up to 150,000 readings in upto 2,500 batches
Measures up to 31mm (1,220mils) of coating on metal substrates with USB and
Bluetooth
®
data output making it compatible with ElcoMaster
®
software.
View up to 8 user selectable
statistics on screen
Rugged and reliable,
ideal for harsh environments
Halve the inspection time
using the scan probe
Large easy to read measurements in
Metric and Imperial units
4
Dry Film Thickness - Digital
* Scan and Auto Repeat Modes require an Elcometer 456 Model T gauge with Scan Probe.
Scan and Auto Repeat Modes
Using the Scan Probe in Scan Mode
Using the Elcometer 456 with the Scan Probe in scan mode enables users
to signicantly reduce dry lm thickness inspection times without aecting
accuracy:
• Slide the Scan Probe over the entire surface area, as the probe is lifted o
the surface the gauge displays the average coating thickness value, the
highest thickness and the lowest thickness values.
• Each set of three readings (average, high and low) can be displayed on the
run graph and stored into the memory.
Using the Scan Probe in Auto Repeat Mode
When the Scan Probe is slid over the coated surface in Auto Repeat Mode*,
a coating thickness reading is taken approximately every half a second. Each
individual dry lm thickness reading is stored into the memory.
With a reading rate in excess of 140 readings per minute, the Auto Repeat
Mode can signicantly speed up the dry lm thickness inspection of large
coated areas.
Separate Coating Thickness GaugeElcometer 456
• During each scan the Elcometer 456 displays the live thickness reading together with an analogue bar
graph
which graphically indicates the thickness relative to both the nominal thickness and any user-dened limits.
