16
Dry Film Thickness - Digital
Accuracy
ae
: ±1-3% or ±20μm ±1-3% or ±1.0mil
Range
d
: 0-5mm 0-200mils
Resolution:
1μm: 0-1mm
10μm: 1-5mm
0.1mil: 0-50mils
1.0mil: 50-200mils
Certicate: ●
Scale 2 Probe Range 0-5mm / 0-200mils
1 2 3 4 5 6 7 8
Probe Range for Separate Coating Thickness GaugeElcometer 456
a. Whichever is the greater
b. FNF (F): FNF probe in F Mode FNF (N): FNF probe in N Mode
Elcometer 456 probes are covered by a 1 year warranty
● Certicate supplied as standard.
X Y
See '#' on the probes table on the opposite page for comparison.
c. Probe length is measured from X to Y
d. Excluding Scan Probe end cap
e. Scan Probe accuracy is ±3% or ±0.02mm (0.8mil) with cap tted, ±1-3% or ±0.02mm
(0.8mil) without cap, when calibrated using a sample of the uncoated substrate.
elcometer.com
17
Dry Film Thickness - Digital
Ferrous (F) Probes
#
Description Probe Length
c
Part Number
Minimum
Headroom
Minimum Sample
Diameter
b
1
Straight Probe 45mm (1.77”) T456CF2S 89mm (3.50”) 8mm (0.32”)
2
Straight Probe
armoured cable 45mm (1.77”) T456CF2ARM 138mm (5.43”) 8mm (0.32”)
3
Scan Probe 45mm (1.77”) T456CF2U 90mm (3.54”) 15mm (0.59”)
4
90° Probe 45mm (1.77”) T456CF2R 32mm (1.26”) 8mm (0.32”)
5
Telescopic Probe
56-122cm (22-48”)
T456CF2T 36mm (1.42”) 8mm (0.32”)
6
Soft Coating Probe 45mm (1.77”) T456CF2B 89mm (3.50”) 8mm (0.32”)
7
Waterproof Probe
1m (3’) cable 45mm (1.77”) T456CF2SW 138mm (5.43”) 8mm (0.32”)
7
Waterproof Probe
5m (15’) cable 45mm (1.77”) T456CF2SW-5 138mm (5.43”) 8mm (0.32”)
7
Waterproof Probe
15m (45’) cable 45mm (1.77”) T456CF2SW-15 138mm (5.43”) 8mm (0.32”)
7
Waterproof Probe
30m (98’) cable 45mm (1.77”) T456CF2SW-30 138mm (5.43”) 8mm (0.32”)
7
Waterproof Probe
50m (164’) cable 45mm (1.77”) T456CF2SW-50 138mm (5.43”) 8mm (0.32”)
7
Waterproof Probe
75m (250’) cable 45mm (1.77”) T456CF2SW-75 138mm (5.43”) 8mm (0.32”)
8
PINIP
™
Integral Probe T456CF2P 174mm (6.85”) 8mm (0.32”)
8
Hi-Temperature PINIP
™
T456CF2PHT 174mm (6.85”) 8mm (0.32”)
Non-Ferrous (N) Probes
#
Description Probe Length
c
Part Number
Minimum
Headroom
Minimum Sample
Diameter
b
1
Straight Probe 45mm (1.77”) T456CN2S 88mm (3.46”) 14mm (0.55”)
8
PINIP
™
Integral Probe T456CN2P 185mm (7.28”) 14mm (0.55”)
Probe Range for Separate Coating Thickness GaugeElcometer 456
c. Probe length is measured from X to Y
d. Excluding Scan Probe end cap
e. Scan Probe accuracy is ±3% or ±0.02mm (0.8mil) with cap tted, ±1-3% or ±0.02mm
(0.8mil) without cap, when calibrated using a sample of the uncoated substrate.
a. Whichever is the greater
b. FNF (F): FNF probe in F Mode FNF (N): FNF probe in N Mode
Elcometer 456 probes are covered by a 1 year warranty
● Certicate supplied as standard.
X Y
18
Dry Film Thickness - Digital
Probe Range for Separate Coating Thickness GaugeElcometer 456
Ferrous (F) Probes
#
Description Probe Length
c
Part Number
Minimum
Headroom
Minimum Sample
Diameter
b
1
Straight Probe 45mm (1.77”)
T456CF3S 102mm (4.02”)
14mm (0.55”)
2
PINIP
™
Integral Probe T456CF3P 184mm (7.24”)
14mm (0.55”)
Non-Ferrous (N) Probes
#
Description Probe Length
c
Part Number
Minimum
Headroom
Minimum Sample
Diameter
b
3
Straight Probe 45mm (1.77”)
T456CN3S
170mm (6.69”) 35mm (1.38”)
Accuracy
a
: ±1-3% or ±50μm ±1-3% or ±2.0mils
Range: 0-13mm 0-500mils
Resolution:
1μm: 0-2mm
10μm: 2-13mm
0.1mil: 0-100mils
1.0mil: 100-500mils
Certicate: ●
Scale 3 Probe Range 0-13mm / 0-500mils
1
2
3
c. Probe length is measured from X to Y
Elcometer 456 probes are covered by a 1 year warranty
a. Whichever is the greater
b. FNF (F): FNF probe in F Mode FNF (N): FNF probe in N Mode
● Certicate supplied as standard.
X Y
See '#' on the probes table on the opposite page for comparison.
