elcometer.com 27 Dry Film Thickness - Digital Model B Model S Model T Automatic calibration; for rapid calibration ■ ■ Calibration memory type; gauge (g) or gauge & batch (gb) g gb gb Number of batches; with unique c…

Dry Film Thickness - Digital

Integral Coating Thickness GaugeElcometer 456

Model B Model S Model T

Fast, accurate reading rate; 70+ readings per minute

■ ■ ■

Repeatable & reproducible measurements

■ ■ ■

Easy to use menu structure; in 30+ languages

■ ■ ■

Tough, impact, waterproof & dust resistant; equivalent to IP64

■ ■ ■

Bright colour screen; with permanent backlight

■ ■ ■

Scratch & solvent resistant display; 2.4” (6cm) TFT

■ ■ ■

Large positive feedback buttons

■ ■ ■

USB power supply; via PC

■ ■ ■

Test certicate

■ ■ ■

2 year gauge warranty

■ ■ ■

Automatic rotating display; 0°, 90°, 180° & 270°

■ ■ ■

Ambient light sensor; with adjustable auto brightness

■ ■ ■

Emergency light

■ ■ ■

Tap awake from sleep

■ ■ ■

Gauge software updates

; via ElcoMaster

software

■ ■ ■

Data output

■ ■ ■

USB; to computer

■ ■ ■

Bluetooth

; to computer, Android

™

& iOS

devices

■ ■

On screen statistics

■ ■ ■

Number of readings; η, Mean (average); x, Standard deviation; σ

Highest reading; Hi, Lowest reading; Lo, Coe󰀩cient of variation;

CV%, Elcometer index value

; EIV

■ ■ ■

Nominal dry lm thickness; NDFT

■ ■

IMO PSPC; %>NDFT, %>90<NDFT, 90:10 pass/fail

■ ■

High & low limits; denable audible & visual alarms

■ ■

Number of readings above high limit;

■ ■

Number of readings below low limit;

■ ■

Live reading trend graph; in Batch Mode

■ ■

ElcoMaster

software & USB cable

□ ■ ■

Replaceable screen protectors

□ ■ ■

Protective case

■ ■ ■

Plastic transit case

□ □ ■

Integral models; with automatic gauge switch on

■ ■ ■

Probe type; Ferrous (F), Non-Ferrous (N), Dual (FNF)

F, N, FNF F, N, FNF F, N, FNF

Measurement range

0-13mm

0-500mils

0-1500μm

0-60mils

0-1500μm

0-60mils

On screen calibration instructions; in 30+ languages

Multiple calibration methods ■ ■ ■

Factory; resets to the factory calibration ■ ■ ■

2-point; for smooth and rough surfaces ■ ■ ■

1-point; zero calibration ■ ■ ■

Zero o󰀨set; for calibration according to ISO19840 ■ ■

Predened calibration & measurement methods ■ ■

ISO, SSPC PA2, Swedish, Australian ■ ■

The Elcometer 456 is supplied with a 1 year warranty against manufacturing defects. The warranty can be extended free of charge to 2 years within 60 days of purchase via

www.elcometer.com. Elcometer 456 probes are covered by a 1 year warranty.

Internet connection required

Visit www.elcometer.com/sdk to nd out how to integrate Elcometer’s MFi certied products to your App.

Elcometer Index Values are used in the automotive industry to assess a coating’s overall quality; USA Patent Number US7606671B2

Product Features

■ Standard □ Optional

elcometer.com

Dry Film Thickness - Digital

Model B Model S Model T

Automatic calibration; for rapid calibration

■ ■

Calibration memory type; gauge (g) or gauge & batch (gb)

g gb gb

Number of batches; with unique calibrations

1 2,500

Calibration memories; 3 user-programmable memories

■

Measurement outside calibration warning

■

Calibration lock; with optional PIN code unlock

■ ■ ■

Delete last reading

■ ■ ■

Gauge memory; number of readings

Last 5 1,500 150,000

Individual batch calibrations; sent to PC via ElcoMaster

software

■ ■

Limits; user definable audible & visual pass/fail warnings

■ ■

Gauge (g) or gauge & batch specic (gb) limits

g gb

Date and time stamp

■ ■

Review, clear & delete batches

■ ■

Batch types; normal, counted average, IMO PSPC

■ ■

Navsea Mode

■

Batch review graph

■

Copy batches and calibration settings

■

Alpha-numeric batch names; user denable on the gauge

■

Scan & Auto Repeat Modes; with Scan probe connected

■

Fixed Batch Size Mode; with batch linking

■

Scale 1

Range: 0-1,500μm (0-60mils) Accuracy

: ±1-3% or ±2.5μm (±0.1mil)

Resolution: 0.1μm: 0-100μm; 1μm: 100-1,500μm (0.01mil: 0-5mils; 0.1mil: 5-60mils)

Model Model B Model S Model T Certicate

Elcometer 456 Ferrous Integral A456CFBI1 A456CFSI1 A456CFTI1 ●

Elcometer 456 Non-Ferrous Integral A456CNBI1

See separate gauges

with N1 PINIP

™

Probe

See separate gauges

with N1 PINIP

™

Probe

●

Elcometer 456 Dual FNF Integral A456CFNFBI1 A456CFNFSI1 A456CFNFTI1 ●

Scale 2

Range: 0-5mm (0-200mils) Accuracy

: ±1-3% or ±20μm (±1.0mil)

Resolution: 1μm: 0-1mm; 10μm: 1-5mm (0.1mil: 0-50mils; 1mil: 50-200mils)

Model Model B Model S Model T Certicate

Elcometer 456 Ferrous Integral A456CFBI2

See separate gauges

with F2 PINIP™ Probe

See separate gauges

with F2 PINIP™ Probe

●

For higher resolution & accuracy on thin coatings Scale 2 gauges can be switched to the Scale 1 mode measurement performance

Scale 3

Range: 0-13mm (0-500mils) Accuracy

: ±1-3% or ±50μm (±2.0mils)

Resolution: 1μm: 0-2mm; 10μm: 2-13mm (0.1mil: 0-100mils; 1mil: 100-500mils)

Model Model B Model S Model T Certicate

Elcometer 456 Ferrous Integral A456CFBI3

See separate gauges

with F3 PINIP™ Probe

See separate gauges

with F3 PINIP™ Probe

●

Display Information 2.4” (6cm) QVGA colour TFT display, 320 x 240 pixels

Battery Type 2 x AA batteries, rechargeable batteries can also be used

Battery Life approximately 24 hours of continuous use at 1 reading per second

Gauge Dimensions (h x w x d) 141 x 73 x 37mm (5.55 x 2.87 x 1.46”)

Gauge Weight (including batteries supplied) 156g (5.50oz)

Operating Temperature -10 to 50°C (14 to 122°F)

Packing List Elcometer 456 gauge, calibration foils, wrist harness, transit case (T),

protective case (B, S, T), 1 x screen protectors (S, T), 2 x AA batteries,

operating instructions, USB cable (S, T), ElcoMaster

software (S, T)

Product Features

■ Standard □ Optional

Technical Specication

Integral Coating Thickness GaugeElcometer 456

Whichever is the greater

Using default settings & lithium batteries, alkaline or rechargeable batteries may di󰀨er ● Certicate supplied as standard.

Dry Film Thickness - Foils & Standards

Calibration foils or ‘shims’ are the most convenient way of creating a coating

thickness standard on the substrate material, surface nish or form. This is the ideal

method for adjusting the calibration of the coating thickness gauge to ensure the

greatest possible accuracy.

Part Number Colour Dimensions Values

Certicate

T99022570-1A Silver 50 x 25mm (1.97 x 0.98”) 12.5µm (0.5mil) ○

T99022570-2A Purple 50 x 25mm (1.97 x 0.98”) 25µm (1.0mil) ○

T99022570-2B Purple 75 x 50mm (2.95 x 1.97”) 25µm (1.0mil) ○

T99022570-4A Dark Blue 50 x 25mm (1.97 x 0.98”) 50µm (2.0mils) ○

T99022570-4B Dark Blue 75 x 50mm (2.95 x 1.97”) 50µm (2.0mils) ○

T99022570-6A Green 50 x 25mm (1.97 x 0.98”) 75µm (3.0mils) ○

T99022570-7A Brown 50 x 25mm (1.97 x 0.98”) 125µm (5.0mils) ○

T99022570-7B Brown 75 x 50mm (2.95 x 1.97”) 125µm (5.0mils) ○

T99022570-9A Peacock Blue 50 x 25mm (1.97 x 0.98”) 175µm (7.0mils) ○

T99022570-10A White 50 x 25mm (1.97 x 0.98”) 250µm (10mils) ○

T99022570-10B White 75 x 50mm (2.95 x 1.97”) 250µm (10mils) ○

T99022570-12A Black 50 x 25mm (1.97 x 0.98”) 500µm (20mils) ○

T99022570-12B Black or Clear 75 x 50mm (2.95 x 1.97”) 500µm (20mils) ○

T99022570-14A Grey-Blue 50 x 25mm (1.97 x 0.98”) 1,000µm (40mils) ○

T99022570-14B Grey-Blue 75 x 50mm (2.95 x 1.97”) 1,000µm (40mils) ○

T99022570-16A Clear 50 x 25mm (1.97 x 0.98”) 1mm (40mils) ○

T99022570-17A O󰀨 White 50 x 25mm (1.97 x 0.98”) 1,500µm (60mils) ○

T99022570-18A Clear 50 x 25mm (1.97 x 0.98”) 2mm (80mils) ○

T99022570-18B Clear 75 x 50mm (2.95 x 1.97”) 2mm (80mils) ○

T99022570-20A Clear 50 x 25mm (1.97 x 0.98”) 3mm (120mils) ○

T99022570-21A Clear 50 x 25mm (1.97 x 0.98”) 4mm (160mils) ○

T99022570-23A Clear 50 x 25mm (1.97 x 0.98”) 8mm (310mils) ○

T99022570-24B Clear 75 x 50mm (2.95 x 1.97”) 9.5mm (370mils) ○

T99022570-25B Grey 75 x 50mm (2.95 x 1.97”) 15mm (590mils) ○

T99022570-26B Grey 75 x 50mm (2.95 x 1.97”) 25mm (980mils) ○

T45618978-2

Grey n/a 1,500µm (60mils) ○

T45618978-3

Grey n/a 5,000µm (197mils) ○

Actual foil values may vary, but are accurately labelled

A certificates can be supplied with any combination of up to 8 Foils (but not As and Bs together)

For use with the high temperature PINIP™ probes only due to the potential high temperature of the sample. Foils supplied in a cap which fits over the PINIP™ probe.

○ Optional Calibration Certificate available.

Individual Precision FoilsElcometer 990

Technical Specication
