Installation Manual, Station Software Version 605.03 SP1 07/2011 Edition
- After an upgrade to the 605.xx software version, calibrate the heads of the D1, D2 and D4 machines.
The temperature compensation is activated for these machines.
3.3 Upgrade from version 601.x or 602.x
When upgrading to the 605.xx software version, please consider following:
CAUTION
For upgrading to the 605.xx software version, please consider the installation manual
"Windows Embedded XP operating system for the MC German and English" (00195327-xx).
Therefore the standard media package (03054699-xx) is required.
- For SIPLACE X4, X2 and X3 machines with CPU 076 the following upgrade packages for the machine
controller are required:
- Upgrade package for SIPLACE X4 with CPU 076 (Item number: 03029123S03) for computer
upgrade to CPU 086
- Upgrade package for SIPLACE X2 and X3 with CPU 076 (Item number: 03051831) for 128 MB
memory expansion
- Fix the temperature warning labels (03031926-01) at the C&P20 head (see the figure).
9 of 48
Installation Manual, Station Software Version 605.03 SP1 07/2011 Edition
- After an upgrade to the 605.xx software version, calibrate the heads of the D1, D2 and D4 machines.
The temperature compensation is activated for these machines.
10 of 48
Installation Manual, Station Software Version 605.03 SP1 07/2011 Edition
4 Requirements
4.1 SIPLACE X-series, D-series and CA-series software components
4.1.1 Station
The station uses the following operating system configuration:
• Station computer: Microsoft Windows XP Professional
(including Service Pack 2 and most recent hotfixes)
• Machine controller: Microsoft Windows embedded XP (SP2)
4.1.2 Machine components
The following versions of other machine components are required for the station software to function
correctly:
Station computer SIPLACE Vision Machine controller SIPLACE Pro
Version 605.03 SP1 Version 413 Version 605.03 SP1 Version 8.0
CAUTION
The functional statuses of the station computer, vision, machine controller and SIPLACE Pro
software must be compatible.
