Installation Manual, Station Software Version 605.03 SP1 07/2011 Edition 4.5 Network configuration Fig. 4-5: Network connections between the machine and SIPLACE Pro A separate private network (100 Mbit) is set up bet wee…

100%1 / 96
Installation Manual, Station Software Version 605.03 SP1 07/2011 Edition
20 of 48
4.4.1 Station computer
Name
SIMATIC Box PC 627
CPU / clock frequency
Pentium M / 2 GHz
RAM
1 GB
Hard disk
40 GB
External DVD drive
Yes
Serial interfaces
1
USB interfaces
and external USB hub
Yes
Network
2x 100 Mbit
Table 4-10: Station computer hardware (configuration of SIPLACE CA-series)
4.4.2 Machine controller
Name
SIMATIC Box PC 627
CPU / clock frequency
Pentium M / 2 GHz
RAM
1 GB
Hard disk
40 GB
External DVD drive
Yes
Serial interfaces
1
USB interfaces
and external USB hub
Yes
Network
2x 100 Mbit
Table 4-11: Machine controller hardware (configuration of SIPLACE CA-series)
4.4.3 Vision computer (optional)
Name
SIMATIC Box PC 627
CPU / clock frequency
Pentium M / 2 GHz
RAM
1 GB
Hard disk
40 GB
External DVD drive
Yes
Serial interfaces
1
USB interfaces and external USB hub
Yes
Network
2x 100 MBit
Table 4-12: Vision computer hardware (optional for SIPLACE CA3 with 3D coplanarity sensor)
Installation Manual, Station Software Version 605.03 SP1 07/2011 Edition
4.5 Network configuration
Fig. 4-5: Network connections between the machine and SIPLACE Pro
A separate private network (100 Mbit) is set up between the station computer (and optionally the Vision
computer) and the machine controller via a subnet mask.
Fixed IP addresses for the station computer, Vision computer and machine controller can thus be assigned
for all SIPLACE machines. These IP addresses are not known outside the private network, for instance in
the SIPLACE LAN or customer LAN.
These IP addresses need not be further configured by the operator while the station software is being
installed.
IP address, station computer
192.168.255.249
IP address, machine controller
192.168.255.250
Vision computer IP Address
192.168.255.251
Subnet mask, station computer/machine controller
255.255.255.248
IP address range, SIPLACE LAN or
IP address range, customer LAN
172.22.xxx.xxx
is configured on-site
Subnet mask for SIPLACE-LAN or
subnet mask for customer LAN
255.255.0.0
is configured on-site
Table 4-13: Network configuration
21 of 48
Installation Manual, Station Software Version 605.03 SP1 07/2011 Edition
5 Installing the station software
NOTICE
The operation system must be installed on the machine controller and Vision computer
before installing the station software.
5.1 Installation sequence
See section 5.2.
See section 5.2.
See the separate installation manual for installing the "Windows
XP operating system" (item no. 00194575-xx)
For calibrating the touch screen, see sections 5.3.3.
See sections 5.3 and 5.4.
See section 5.5.
