3 ブロアユニット:SPG Blower Unit:SPG パーツレイアウト Kit No. キット 品番 Kit Name キット名称 N610140104AA セクションNo. PARTS LAYOUT Section No. - - O11 ( KN610140104AA-11 )
Ref
No.
Remarks R
1
Q'ty
2
搬送固定ブラケット(ユニバーサルマスクホルダ):SPG
Fixed Bracket (Universal Mask Holder): SPG
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610140096AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 N210174812AA
BRACKET
1
2 N210174813AA
BRACKET
1
3 N210182181AA
BRACKET
1
4 N210182201AA
BOLT
8
5 N510019942AA WA SOCKET SP TYPE M5X16-10.9 A2J (Trivalent)
O10
--
( KN610140096AA-01 )
3
ブロアユニット:SPG
Blower Unit:SPG
パーツレイアウト
Kit No.
キット品番
Kit Name
キット名称
N610140104AA
セクションNo.
PARTS LAYOUT
Section No.
--
O11
( KN610140104AA-11 )
Ref
No.
Remarks R
1
Q'ty
3
ブロアユニット:SPG
Blower Unit:SPG
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610140104AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
BLOCK
1
1 MTPB006857AA
PLATE
1
2 N210181655AA
STOPPER
1
3 N210181656AA
COVER
1
4 N210181425AA
PLATE
1
5 N210174130AB
CLAMP
1
6 N210174131AA
CLAMP
1
7 N210174133AA
PLATE
1
8 MTPB014160AA
PLATE
1
9 N210181657AA
SOCKET
3
11 N610014951AA
BLOWER
1
12 N510054135AA
S
VB-007G2-PFSC
FILTER
1
13 N932VBLF020 VBLF-020
NIPPLE
4
14 N510048016AA (Rni)1 1/2X1
JOINT
2
15 N510019630AA (SL)1
BAND
4
16 N462SY38-026 SY38 SS-Zn
VALVE
1
17 N510064063AA VQZ1121-5MOZ1-C4-F-X543-Q
JOINT
1
18 N510066669AA KQ2L04-08A
SPACER
4
19 N510015195AA ASF-452E
SPACER
1
20 N510020913AA ASF-455E
CYLINDER
1
21 N510065311AA CQSWB20-20D
SPEED-CONTROLLER
2
22 KXF00YYAA00 AS1301F-M5-04
SPACER
4
23 N510023032AA 3382330-30030
SPACER
4
24 N510029488AA ASF-476E
BOLT
4
25 N510017416AA
Hexagon socket head cap screw M5X70-10.9 A2J (Trivalent)
BAND
5
26 N510011271AA G-12
HOSE
1
27 N510011280AA TAC Eco Duct D38
TUBE
1
28 KXF03PPAA00 TFU0425B-2
CABLE-SUPPORT
1
29 N510048517AA FT4
TUBE
1
31 KXF03TEAA00 TU0425B-20
BOLT
2
32 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
20
33 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
11
34 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
4
35 N510017433AA
Hexagon socket head cap screw M6X16-10.9 A2J (Trivalent)
WASHER
2
36 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
WASHER
4
37 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
BOLT
4
38 N510017166AA
Hexagon socket head cap screw M10X25-10.9 A2J (Trivalent)
WASHER
4
39 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
WASHER
17
40 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
10
41 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
4
42 N510018501AA
Round finish plain washer 6 10H A2J (Trivalent)
WASHER
4
43 N510018505AA
Round finish plain washer 10 10H A2J (Trivalent)
WASHER
3
44 N510020099AA Thick washer M4
BOLT
4
45 N510017305AA
Hexagon socket head cap screw M3X10-10.9 A2J (Trivalent)
BOLT
6
46 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
SCREW
5
47 N510018367AA
Hexagon socket set screw Cup point M4X16-45H A2J (Trivalent)
BUSH
1
48 KXF0B5WAA00 NSL-18
BRACKET
1
49 KXFB0056A00
O12
--
( KN610140104AA-11 )
