N7202A029B40_SPG_Parts List_零件部品一覽表.pdf - 第42页
1-H 本体部:SPG Main Body :SPG パーツレイアウト Kit No. キット 品番 Kit Name キット名称 N610140062AA セクションNo. PARTS LAYOUT Section No. - - S15 ( KN610140062AA-24-8 )
Ref
No.
Remarks R
1
Q'ty
1-G
本体部:SPG
Main Body:SPG
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610140062AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 N210173342AA
SENSOR(350mm)
1
3 N610147530AB
REGULATOR-UNIT
1
4 N510064053AA AWM20-02B-X2192
NIPPLE
1
5 N510021600AA VRN-0302
JOINT
1
6 N510019582AA (T)3/8
PLUG
1
7 N433PT03-041 PT3/8 1-Type
HOSE
1
8 N510002541AA OUA8X12-5M-03B
JOINT
1
9 N510066656AA KQ2L12-02AS
BOTTLE
1
10 KXF07M8AA00 5-010-03
BAND
1
11 N510011271AA G-12
SLIT
2
12 N510064040AA OS-CX-1X6
SPACER
4
13 N510038215AA ASF-635E
SCREW
4
14 N510020565AA
Hexagon socket set screw Cup point M6X25-45H A2J (Trivalent)
BOLT
4
15 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
2
16 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
2
17 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
WASHER
2
19 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
4
20 N510018501AA
Round finish plain washer 6 10H A2J (Trivalent)
WASHER
4
21 N510020098AA Thick washer M3
WASHER
2
22 N510020100AA Thick washer M5
WASHER
4
23 N510018327AA Spring lock washer No.2 3 S A2J (Trivalent)
BOLT
4
25 N510017428AA
Hexagon socket head cap screw M6X12-10.9 A2J (Trivalent)
BOLT
1
26 N510017435AA
Hexagon socket head cap screw M6X20-10.9 A2J (Trivalent)
NUT
1
27 N510017867AA
Hexagon nut Type-1 Best class M6-6H-4T A2J (Trivalent)
S14
--
( KN610140062AA-24-7 )
1-H
本体部:SPG
Main Body:SPG
パーツレイアウト
Kit No.
キット品番
Kit Name
キット名称
N610140062AA
セクションNo.
PARTS LAYOUT
Section No.
--
S15
( KN610140062AA-24-8 )
Ref
No.
Remarks R
1
Q'ty
1-H
本体部:SPG
Main Body:SPG
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610140062AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 N210173335AB
VALVE
1
2 N510058865AA
S
VP344T-5LOZ1-02A-X528
MANIFOLD
1
3 KXF029YAA00 KM11-08-12-6
JOINT
1
4 N510066657AA KQ2L08-12A
JOINT
1
5 N510066658AA KQ2R06-08A
JOINT
1
6 N510066640AA KQ2X06-08A
JOINT
3
7 KXF0DZKRA00 KQ2P-08
JOINT
1
8 N510066659AA KQ2U08-00A
JOINT
1
9 N510066660AA KQ2R04-08A
REGULATOR
1
10 N510016408AA IR2010-02-DIJ00454
REGULATOR
1
11 MTNP001188AA AR20K-01H-B-X2111A
TUBE
1
12 KXF03VCAA00 TU1208B-20
TUBE
1
13 KXF03UQAA00 TU0805B-20
TUBE
1
14 KXF03U6AA00 TU0604B-20
TUBE
1
15 KXF03TEAA00 TU0425B-20
WASHER
2
16 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
WASHER
4
17 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
2
18 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
4
19 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
BOLT
2
20 N510017359AA
Hexagon socket head cap screw M4X25-10.9 A2J (Trivalent)
BOLT
2
21 N510017361AA
Hexagon socket head cap screw M4X30-10.9 A2J (Trivalent)
BOLT
2
22 N510017386AA
Hexagon socket head cap screw M5X10-10.9 A2J (Trivalent)
BOLT
2
23 N510017354AA
Hexagon socket head cap screw M4X20-10.9 A2J (Trivalent)
S16
--
( KN610140062AA-24-8 )
