SM411_TRM(Ver12.0_CS16.50).pdf - 第124页
Page HANWHA TECHWIN 11 2 SM411 Electric Control Part
Page
HANWHA TECHWIN
111
SM411
Electric Device Ass’y (4/4)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1 J90511012A CONVEYOR_STEP_MOTOR_DRIVER_ASSY 1
2 EP06-000283 SERVO CONTROL-DRIVE-BELT STEP DRIVER 4 J31521023A/ EP06-900111
3 EP06-900107 R_AXIS_DRIVER_MD5_HD14_3X MD5_HD14_3X 2 EP06-900103
4 J91741023A SM411_CONVEYOR_PWR_BOARD 2
5 1
6 1
7 1
8 1
Page
HANWHA TECHWIN
112
SM411
Electric Control Part
Page
HANWHA TECHWIN
113
SM411
Blank
