Machine Automati on Controller NX1P 16 Optional Products/Maintenance Products/DIN Track Accessories *1. EtherCAT junction slaves cannot be used for EtherNet/IP and Ethernet. *2. Industrial switching hubs cannot be used f…

Machine Automation Controller NX1P

Recommended EtherCAT and EtherNet/IP Communications Cables

Use Straight STP (shielded twisted-pair) cable of category 5 or higher with double shielding (braiding and aluminum foil tape) for EtherCAT.

For EtherNet/IP, required specification for the communications cables varies depending on the baud rate.

For 100BASE-TX/10BASE-T, use an STP (shielded twisted-pair) cable of Ethernet category 5 or higher.

Cable with Connectors

*1. Cables with standard RJ45 plugs are available in the following lengths: 0.2 m, 0.3 m, 0.5 m, 1 m, 1.5 m, 2 m, 3 m, 5 m, 7.5 m, 10 m, 15 m, 20 m.

Cables with rugged RJ45 plugs are available in the following lengths: 0.3 m, 0.5 m, 1 m, 2 m, 3 m, 5 m, 10 m, 15 m.

For details, refer to the Industrial Ethernet Connectors Catalog (Cat. No. G019).

*2. Cable colors are available in yellow, green, and blue.

*3. For details, contact your OMRON representative.

*4. The products can be used only with the NX701/NX502.

Cables / Connectors

*1. We recommend you to use the above Cable and RJ45 Connector together.

*2. The products can be used only with the NX701/NX502.

*3. We recommend you to use the above Cable and RJ45 Assembly Connector together.

Item

Recommended

manufacturer

Cable length (m) Model

Wire Gauge and Number of Pairs:

AWG26, 4-pair Cable

Cable Sheath material: PUR

Cable with Connectors on Both Ends

(RJ45/RJ45)

Standard RJ45 plug type *1

Cable color: Yellow *2

EtherCAT/

EtherNet/IP (10BASE/100BASE/1000BASE *4)

OMRON

0.3 XS6W-6PUR8SS30CM-YF

0.5 XS6W-6PUR8SS50CM-YF

1 XS6W-6PUR8SS100CM-YF

2 XS6W-6PUR8SS200CM-YF

3 XS6W-6PUR8SS300CM-YF

5 XS6W-6PUR8SS500CM-YF

Wire Gauge and Number of Pairs:

AWG22, 2-pair cable

Cable with Connectors on Both Ends

(RJ45/RJ45)

Rugged RJ45 plug type *1

Cable color: Light blue

EtherCAT/

EtherNet/IP (10BASE/100BASE)

OMRON

0.3 XS5W-T421-AMD-K

0.5 XS5W-T421-BMD-K

1 XS5W-T421-CMD-K

2 XS5W-T421-DMD-K

5 XS5W-T421-GMD-K

10 XS5W-T421-JMD-K

Cable with Connectors on Both Ends

(M12 Straight/M12 Straight)

Shield Strengthening Connector cable *3

M12/Smartclick Connectors

Cable color: Black

EtherCAT/

EtherNet/IP (10BASE/100BASE)

OMRON

0.5 XS5W-T421-BM2-SS

1 XS5W-T421-CM2-SS

2 XS5W-T421-DM2-SS

3 XS5W-T421-EM2-SS

5 XS5W-T421-GM2-SS

10 XS5W-T421-JM2-SS

Cable with Connectors on Both Ends

(M12 Straight/RJ45)

Shield Strengthening Connector cable *3

M12/Smartclick Connectors

Rugged RJ45 plug type

Cable color: Black

EtherCAT/

EtherNet/IP (10BASE/100BASE)

OMRON

0.5 XS5W-T421-BMC-SS

1 XS5W-T421-CMC-SS

2 XS5W-T421-DMC-SS

3 XS5W-T421-EMC-SS

5 XS5W-T421-GMC-SS

10 XS5W-T421-JMC-SS

Item Recommended manufacturer Model

Products for EtherCAT or

EtherNet/IP

(1000BASE-T

/100BASE-TX)

Wire Gauge and Number of

Pairs: AWG24, 4-pair

Cable

Cables

Kuramo Electric Co.

KETH-SB *1

RJ45 Connectors Panduit Corporation

MPS588-C *1

Products for EtherCAT or

EtherNet/IP

(100BASE-TX/10BASE-T)

Wire Gauge and Number of

Pairs: AWG22, 2-pair

Cable

Cables Kuramo Electric Co. KETH-PSB-OMR *3

JMACS Japan Co., Ltd. PNET/B *3

RJ45 Assembly Connector OMRON

XS6G-T421-1 *3

Machine Automation Controller NX1P

Optional Products/Maintenance Products/DIN Track Accessories

*1. EtherCAT junction slaves cannot be used for EtherNet/IP and Ethernet.

*2. Industrial switching hubs cannot be used for EtherCAT.

*3. There are restrictions on the combination of CPU Unit version and memory card. Refer to NJ/NX-series CPU Unit Software User's Manual

(W501) 8-5-2 Specifications of Supported SD Memory Cards, Folders, and Files for details.

*4. Use the NX-END02 End Cover only for the CPU Unit and the NX-END01 End Cover only for the EtherCAT Coupler Unit.

Product Name Specification Model

EtherCAT junction

slaves *1

3 ports. Power supply voltage: 20.4 to 28.8 VDC (24 VDC -15 to +20%).

Current consumption (A): 0.08

GX-JC03

6 ports. Power supply voltage: 20.4 to 28.8 VDC (24 VDC -15 to +20%).

Current consumption (A): 0.17

GX-JC06

Industrial Switching

Hubs for EtherNet/IP and

Ethernet *2

Quality of Service (QoS):

EtherNet/IP control data priority

10/100BASE-TX, Auto-Negotiation

5 ports. Current consumption (A): 0.07

Power supply connector included.

W4S1-05D

Memory Cards *3

SD memory card, 2 GB HMC-SD292

SDHC memory card, 4 GB HMC-SD492

SDHC memory card, 16GB HMC-SD1A2

Battery

The battery is not mounted when the product is shipped.

To turn OFF the power supply to the equipment for a certain period of time by using the clock data for programming,

event logs, etc., you need a separately-sold battery to retain the clock data. Refer to the Battery page for details.

CJ1W-BAT01

End Cover

(For NX1P2 CPU Unit) *4

Must be connected to the right end of the CPU Rack.

One End Cover is provided with the CPU Unit.

NX-END02

End Cover

(For EtherCAT Coupler

Unit) *4

One End Cover is provided with the EtherCAT Coupler Unit. NX-END01

DIN Tracks

Length: 0.5 m; Height: 7.3 mm PFP-50N

Length: 1 m; Height: 7.3 mm PFP-100N

End Plate

There are 2 stoppers provided with CPU Units and I/O Interface Units as standard accessories to secure the Units on

the DIN Track.

PFP-M

Unit/Terminal Block

Coding Pins

For 10 Units

(Terminal Block: 30 pins, Unit: 30 pins)

NX-AUX02

DIN Track Insulation

Spacers

A Spacer to insulate the control panel from the DIN Track.

To insulate the EtherCAT Slave Terminal from the control panel, use Din Track Insulation Spacers.

NX-AUX01

Product Name

Specification

Model

No. of terminals

Terminal number

indications

Ground terminal mark

Terminal current

capacity

Terminal Blocks

8A/B

None

10 A

NX-TBA082

12 A/B NX-TBA122

16 A/B NX-TBA162

16 C/D NX-TBB162

12 C/D NX-TBB122

16 C/D NX-TBB162

8A/B

Provided

NX-TBC082

16 A/B NX-TBC162

Machine Automation Controller NX1P

Electrical and Mechanical Specifications

*1. Includes the End Cover, and does not include projecting parts.

*2. Includes the End Cover. The weight of the End Cover is 82 g.

*3. Includes the SD Memory Card and Option Board. The NX Unit power consumption to NX Units is not included.

*4. The inrush current may vary depending on the operating condition and other conditions. Therefore, select fuses, breakers, and external power

supply devices that have enough margin in characteristic and capacity, considering the condition under which the devices are used.

*5. The amount of current that can be passed constantly through the terminal. Do no exceed this current value when you use a through-wiring for

the Unit power supply.

*6. When the type of the I/O power supply to NX Units you use is the supply from NX bus, an Additional I/O Power Supply Unit is required. The

maximum I/O power supply current from an Additional I/O Power Supply Unit is 4 A. Refer to the NX-series NX1P2 CPU Unit Hardware User’s

Manual (Cat. No. W578) for details.

General Specifications

*1. Refer to the OMRON website (https://www.ia.omron.com/) or consult your OMRON representative for the most recent applicable standards for

each model.

Item Specification

Model NX1P2-140DT NX1P2-9024DT

Enclosure Mounted in a panel

Dimensions (mm) *1 154 × 100 × 71 mm (W×H×D) 130 × 100 × 71 mm (W×H×D)

Weight *2

NX1P2-140DT: 650 g

NX1P2-140DT1: 660 g

NX1P2-9024DT: 590 g

NX1P2-9024DT1: 590 g

Unit power supply

Power supply voltage 24 VDC (20.4 to 28.8 VDC)

Unit power consumption *3

NX1P2-140DT: 7.05 W

NX1P2-140DT1: 6.85 W

NX1P2-9024DT: 6.70 W

NX1P2-9024DT1: 6.40 W

Inrush current *4

For cold start at room temperature:

10 A max./0.1 ms max.

and

2.5 A max./150 ms max.

Current capacity of power

supply terminal *5

4 A max.

Isolation method No isolation: between the Unit power supply terminal and internal circuit

Power supply to the NX Unit

power supply

NX Unit power supply capacity 10 W max.

NX Unit power supply efficiency 80 %

Isolation method No isolation: between the Unit power supply terminal and NX Unit power supply

I/O Power Supply to NX Units Not provided *6

External connection terminals

Communication connector

RJ45 for EtherNet/IP Communications × 1

RJ45 for EtherCAT Communications × 1

Screwless clamping terminal

block

For Unit power supply input, grounding, and input signal: 1 (Removable)

For output signal: 1 (Removable)

Output terminal (service supply) Not provided

RUN output terminal Not provided

NX bus connector 8 NX Units can be connected

Option board slot 21

Item Specification

Enclosure Mounted in a panel

Grounding method Ground to less than 100 Ω.

Operating environment

Ambient operating temperature 0 to 55°C

Ambient operating humidity 10% to 95% (with no condensation)

Atmosphere Must be free from corrosive gases.

Ambient storage temperature -25 to 70°C (excluding battery)

Altitude 2,000 m max.

Pollution degree 2 or less: Meets IEC 61010-2-201.

Noise immunity 2 kV on power supply line (Conforms to IEC 61000-4-4.)

Overvoltage category Category II: Meets IEC 61010-2-201.

EMC immunity level Zone B

Vibration resistance

Conforms to IEC 60068-2-6.

5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz, acceleration of 9.8 m/s

100 min each in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total)

Shock resistance

Conforms to IEC 60068-2-27.

147 m/s

, 3 times in X, Y, and Z directions

Battery

Life 5 years (Power ON time rate 0% (power OFF))

Model CJ1W-BAT01 (sold separately)

Applicable standards *1 cULus, EU, UKCA, RCM, KC, NK, LR
