SIPLACE Pro 15.1 (R18-1) / Version Description 05/2018 Edition
10
3 Prerequisites
NOTICE
System requirements
The Support Media checks the necessary system requirements of your system and
installs these. Amongst others e.g. Microsoft .NET Framework, the ASM License
Manager, the ASM Error Reporter Service and the ASM Operation Manager.
The use of the ASM Support Media 2.7 (R18-1) is mandatory.
The system requirements (supported operating systems and database variants) and an
overview of the interoperable products can be found in the ASM Support Media 2.7
(R18-1) Software Version Description, item no. [00900052-xx].
SIPLACE Pro requires an NTFS partition for the installation. FAT or FAT32 file systems are not
supported.
3.1 Supported Station Software Versions and Machine Types
Station Software
Version
Machine Types
711 DX-series: DX1, DX2
SX-series: SX1/SX2, SX1/SX2 V2
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA4, CA4 V2
TX-series: TX1, TX2, TX2i, TX2 micron, TX2i micron
TX1 V2, TX2 V2, TX2i V2
710 DX-series: DX1, DX2
SX-series: SX1/SX2, SX1/SX2 V2
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA4
TX-series: TX1, TX2, TX2i, TX2 micron, TX2i micron
709 DX-series: DX1, DX2
SX-series: SX1/SX2, SX1/SX2 V2
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA4
TX-series: TX1, TX2, TX2i
SIPLACE Pro 15.1 (R18-1) / Version Description 05/2018 Edition
11
708 DX-series: DX1, DX2
SX-series: SX1/SX2, SX1/SX2 V2
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA4
605 D-series: D1, D2, D4
Table 3-1: Supported station software versions and machine types
NOTICE
As stated in the discontinuation decision for software version 505 dated December 20,
2010, ASM Assembly Systems has finally discontinued the corresponding station
software platforms 40x and 50x for the SIPLACE S2x, SIPLACE F4, SIPLACE F5,
SIPLACE F5-HM as well as the SIPLACE HSx and SIPLACE HFx machine generations
as of July 31, 2017.
Since the mentioned SIPLACE machine generations are still in use in many productions,
electronics manufacturers in the field can continue to operate these machines with the
current SIPLACE Pro and Setup Center versions for the present.
We ask for your understanding that ASM cannot guarantee that such configured
machines can be operated in full functionality and in any combination with newer
machine generations.
If functional restrictions should occur in rare cases on the SIPLACE S2x, SIPLACE F4,
SIPLACE F5, SIPLACE F5-HM as well as on the SIPLACE HSx and SIPLACE HFx
machines, ASM Assembly Systems is not obliged to correct the error due to the
discontinuation decision specified above.
ASM Assembly Systems reserves the right to finally discontinue support for the SIPLACE
S2x, SIPLACE F4, SIPLACE F5, SIPLACE F5-HM as well as the SIPLACE HSx and
SIPLACE HFx placement machines in the SIPLACE Pro and Setup Center software
products, after having issued a timely adequate advance notice.
3.2 Supported DEK Printer Software Versions and Printer Types
DEK Printer Version Printer Types
DEK Printer Software Version V10
(Printer Programming 2.0)
DEK Printers running V10.6 software
*)
DEK Printer Software Version V09
(Printer Programming 1.0)
DEK Printers running V09 software
*)
Table 3-2: Supported DEK printer software versions and printer types
*)
The version number listed above is accurate at the time of compiling this document.
Please note that it is subject to change without prior notice. For further details please contact your
sales representative.
SIPLACE Pro 15.1 (R18-1) / Version Description 05/2018 Edition
12
3.3 Supported Feeder Types
The following feeders are supported by SIPLACE Pro:
Modules from ASM Assembly Systems
– 4 mm – 104 mm X-feeder
– 8 mm - 88 mm E (E-series only)
– 2x8 mm X-feeder
– 16 mm XN-feeder
– Surftape AX (8 mm, 12 mm, 16 mm)
– LED feeder TE
LED feeder HS
– SIPLACE Glue Feeder
– SIPLACE JTF-S (X-series S and SX1/SX2 V2 only)
– SIPLACE JTF-M (X-series S, X4i S micron and SX1/SX2 V2 only)
– SIPLACE JTF-ML 14X and JTF-ML 18X (TX-series only)
– SIPLACE JTF-ML2 7/7 and JTF-ML2 9/9 (TX-series only)
– JTF-MW E (E-series only)
– SIPLACE BulkFeeder X
– Arbitrary Carrier X
– Conveyor Carrier X
– Carrier X (XTH) (X2, X3, X4 on location 2 and 4 only)
– Carrier SX (SX1/SX2 with Twin Head and CPP head only)
– Stick feeder with X-adapter
– Label feeder with X-adapter
– Reject conveyor with X-adapter
– Linear Dipping Module X
– Linear Dipping Unit 2 X
– Linear Dipping Unit 2 E (E-series only)
– MTC2 (X2, X3, X4 on location 2 and 4, X2 S, X3 S, X4 S on location 2)
– WPC5 / WPC6 (SX1/SX2, X-series S on location 2)
– SIPLACE Wafer Systems (CA-series only)
– Splice sensor X-feeder
Modules from 3
rd
party suppliers
– FFI feeders:
Data IO RoadRunners
– IPTE Multi Stick Feeder:
IPTE MSF 60 AX
IPTE MSF XL80 AX
– SEMO CRF80 tape feeder
