SIPLACE Pro 15.1 (R18-1) / Version Description 05/2018 Edition
11
708 DX-series: DX1, DX2
SX-series: SX1/SX2, SX1/SX2 V2
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA4
605 D-series: D1, D2, D4
Table 3-1: Supported station software versions and machine types
NOTICE
As stated in the discontinuation decision for software version 505 dated December 20,
2010, ASM Assembly Systems has finally discontinued the corresponding station
software platforms 40x and 50x for the SIPLACE S2x, SIPLACE F4, SIPLACE F5,
SIPLACE F5-HM as well as the SIPLACE HSx and SIPLACE HFx machine generations
as of July 31, 2017.
electronics manufacturers in the field can continue to operate these machines with the
current SIPLACE Pro and Setup Center versions for the present.
We ask for your understanding that ASM cannot guarantee that such configured
machines can be operated in full functionality and in any combination with newer
machine generations.
If functional restrictions should occur in rare cases on the SIPLACE S2x, SIPLACE F4,
SIPLACE F5, SIPLACE F5-HM as well as on the SIPLACE HSx and SIPLACE HFx
machines, ASM Assembly Systems is not obliged to correct the error due to the
discontinuation decision specified above.
S2x, SIPLACE F4, SIPLACE F5, SIPLACE F5-HM as well as the SIPLACE HSx and
SIPLACE HFx placement machines in the SIPLACE Pro and Setup Center software
3.2 Supported DEK Printer Software Versions and Printer Types
DEK Printer Version Printer Types
DEK Printer Software Version V10
(Printer Programming 2.0)
DEK Printers running V10.6 software
*)
DEK Printer Software Version V09
(Printer Programming 1.0)
DEK Printers running V09 software
*)
Table 3-2: Supported DEK printer software versions and printer types
*)
The version number listed above is accurate at the time of compiling this document.
Please note that it is subject to change without prior notice. For further details please contact your
sales representative.
SIPLACE Pro 15.1 (R18-1) / Version Description 05/2018 Edition
12
3.3 Supported Feeder Types
The following feeders are supported by SIPLACE Pro:
Modules from ASM Assembly Systems
– 4 mm – 104 mm X-feeder
– 8 mm - 88 mm E (E-series only)
– 2x8 mm X-feeder
– 16 mm XN-feeder
– Surftape AX (8 mm, 12 mm, 16 mm)
– LED feeder TE
LED feeder HS
– SIPLACE Glue Feeder
– SIPLACE JTF-S (X-series S and SX1/SX2 V2 only)
– SIPLACE JTF-M (X-series S, X4i S micron and SX1/SX2 V2 only)
– SIPLACE JTF-ML 14X and JTF-ML 18X (TX-series only)
– SIPLACE JTF-ML2 7/7 and JTF-ML2 9/9 (TX-series only)
– JTF-MW E (E-series only)
– SIPLACE BulkFeeder X
– Arbitrary Carrier X
– Conveyor Carrier X
– Carrier X (XTH) (X2, X3, X4 on location 2 and 4 only)
– Carrier SX (SX1/SX2 with Twin Head and CPP head only)
– Stick feeder with X-adapter
– Label feeder with X-adapter
– Reject conveyor with X-adapter
– Linear Dipping Module X
– Linear Dipping Unit 2 X
– Linear Dipping Unit 2 E (E-series only)
– MTC2 (X2, X3, X4 on location 2 and 4, X2 S, X3 S, X4 S on location 2)
– WPC5 / WPC6 (SX1/SX2, X-series S on location 2)
– SIPLACE Wafer Systems (CA-series only)
– Splice sensor X-feeder
Modules from 3
rd
party suppliers
– FFI feeders:
Data IO RoadRunners
– IPTE Multi Stick Feeder:
IPTE MSF 60 AX
IPTE MSF XL80 AX
– SEMO CRF80 tape feeder
SIPLACE Pro 15.1 (R18-1) / Version Description 05/2018 Edition
13
4 Features of SIPLACE Pro 15.1
If not differently described, the features of the previous SIPLACE Pro versions are contained in
SIPLACE Pro 15.1. The main new features of SIPLACE Pro 15.1 are listed below.
Detailed information on the individual functions can be found in the Online Help for
4.1 SIPLACE TX V2 – New Placement Machine
The new SIPLACE TX V2 placement machine supports placement on a dual conveyor system. The
placement machine is available in three configurations: TX1 V2 (single gantry), TX2 V2 (dual
gantry) and TX2i V2 (dual gantry, inner table). The dual conveyor can be used as single conveyor
in Flexible Dual Lane mode when boards with at width > 260 mm are placed. In this case, the
Flexible Dual Lane – Machine Connection Bound license is required.
4.2 SIPLACE C&P20 P2 – New Placement Head
The new SIPLACE C&P20 P2 placement head is supported on the SIPLACE TX V2 placement
machine. A new 6xxx nozzle series has been introduced for this placement head together with the
new 6xxx (20) nozzle magazine (NC C&P 20 P2 6xxx 1x3 and NC C&P 20 P2 6xxx 2x2 nozzle
changers). This nozzle series is also supported by the C&P20 P placement head.
The placement head is able to pick up components with very low force when selected in the
Handling tab of the Component Shape Editor (please refer to section 5.5).
4.3 New X-Feeders
To support the high placement performance of the SIPLACE C&P20 P2 placement head, new
4 mm X, 8 mm X and 2 x 8 mm X feeders have been introduced.
These feeders are compatible with the correspondent previous X-feeders. The feeder types remain
unchanged in SIPLACE Pro. However, their maximum performance depends on the placement
head that uses the feeder.
Using an X-feeder of the previous type together with the SIPLACE C&P20 P2 placement head may
lead to decreased placement performance since the new X-feeder provides optimizations that only
work together with this placement head. In other situations, both feeders behave identical.
The respective "official" product names SIPLACE SmartFeeder X (previous type) and
