WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
48
PROGRAMMING
Learn to Setup Device
Available only in the 4500E mode, this feature is similar to CLOSE CLAMP AT LOOP HEIGHT, and allows the
operator to have more control over the loop shape. Closing the clamps at second search is not as
noticeable in most applications, however, if N
UDGE-UP is being used then it becomes absolutely
necessary to have the clamps close at this second search elevation.
4500E
ONLY
Close CLAMP AT SEARCH above Bond #2:
5=Close
8=Suggest
A=Prev option 0=Open G=Next option
Æ
PRESS KEY G
Å
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
49
ADVANCED PROGRAMMING
Main Edit Menu
MAIN EDIT MENU
EDIT 0=Edit loop motion
4=Repeat last edit 6=Machine setup
7=Device edit 9=Wire type edit
A=Bond edit G=Learn mode
1 or 3 = Exit Edit
2 = Go To Device/Type
4 = Repeat Last Edit
5 = Info
ϑ To call “Main Edit Menu”
From the “Home” Menu, Press 4 (Edit)
Key Format:
Escape
1
Go To
Device/Type
2
Home
3
Repeat
Last Edit
4
Info
5
Machine
Setup
6
Device Edit
7
8
Wire
Type Edit
9
Bond Edit
A
Edit
Loop
Motion 0
Learn Mode
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
50
ADVANCED PROGRAMMING
Machine Setup Menus
F
OR 4500E AND 4600E MODES ONLY
MACHINE SETTINGS MENU #1
Machine Settings Menu #1
4=Clamp home 5=Wire pull 6= Wire tail
7=Dual force 8=Force adjust 9=Restart ht
A=Prev menu 0=More options G=Sequence
1 = Edit Menu, 3 = Home,
0 = Machine Settings Menu #2
G = Sequence – This will step the operation through
the machine settings of both Menu #1 and Menu #2
ϑ To call “Edit Machine Settings Menu #1”
From the H
OME menu press 4 (EDIT), and then press 6 (MACHINE).
Key Format:
Previous
Menu
1
2
Home
3
Clamp home
4
Wire pull
5
Wire tail
6
Dual force
7
Force adjust
8
Restart
height
9
Previous
Menu
A
More
options
0
Sequence
G
