WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
77
ADVANCED PROGRAMMING
Copy Type
This menu enables the operator to copy types of wires to another type within a device.
COPY TYPE
COPY TYPE 2 of 3 to Type: 3
4=Key in 5=Next Destination
7=Prev source 9=Next source
A=Prev menu 0=Prev destination G=OK
Key “5” can advance one past the last type #
which is also the default
Key “G” performs the copy and goes to the Edit
Type Menu.
To Call “Copy Type”
From the H
OME menu press 4 (EDIT), 9 (WIRE TYPE EDIT), and then 6 (COPY TYPE)
Key Format:
Previous
Menu
1
Go To
Device/Type
2
Home
3
Key in
4
Next bond
5
6
Previous
Source
7
8
Next
Source
9
Previous
Menu
A
Previous
bond
0
OK
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
78
ADVANCED PROGRAMMING
Bond Edit Menu
This menu is the starting point for the editing of the bond parameters for a specified type.
BOND EDIT MENU
Device 2: Type 1 of 3 (2 bonds)
4=Edit bond 5=# of bonds
7=Prev type 8=Type 1 9=Next Type
A=Prev menu
To Call “Bond Edit” Menu
From the H
OME menu press 4 (EDIT) and then press A (BOND EDIT)
Key Format:
Previous
Menu
1
Go To
Device/Type
2
Home
3
Edit bond
4
# of bonds
5
6
Previous
type
7
Type 1
8
Next type
9
Previous
Menu
A
0
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
79
ADVANCED PROGRAMMING
Edit Bond
This option allows the operator to edit the following data: Ultrasonic Power, Ultrasonic Time, Bond Force,
Bond Depth, Inhibit Auto Mode, Speed and Pre-Bond Delay.
EDIT BOND
Device 2 Type 3: Bond #1 of 5
4=U/S power 5=U/S time 6=Force
7=Depth 8=Inhibit auto 9=Speed
A=Prev menu 0=Bond delay G=Sequence
To Call “Edit Bond” Menu
From the H
OME menu press 4 (EDIT), A (BOND EDIT), and then press 4 (EDIT BOND)
Key Format:
Previous
Menu
1
Go To
Device/Type
2
Home
3
U/S power
4
U/S time
5
6
Depth
7
Inhibit auto
8
Speed
9
Previous
Menu
A
Bond delay
0
Sequence
G
