WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
89
ADVANCED PROGRAMMING
Edit Loop Menu
The operator can set up the machine’s loop shape in one of two ways. From the main EDIT LOOP MENU
key G can be pressed and the machine will walk the operator through all of the loop shape settings. Or, if
key 4 is selected, the user can modify each setting individually.
EDIT LOOP MENU 4=Loop Edit
Device 1, Type 1: (2 Bonds)
-> LOOK IN MICROSCOPE,
SELECT BOND 1 AND PRESS G WHEN READY
G = Sequence through each of the items listed
in the screen shot below
4 = For more advanced users- allows operator
to change the loop settings individually.
LOOP EDIT: Type 1 of 1
4=Search 5=Z-Before-Y 6=Backbend
7=Loop elev 8=Y offset 9=Clamp mode
A=Home menu 0=Loop pull G=Nudge-up
The Clamp Mode feature is only available in
the 4500E mode.
ϑ To call “Loop Menu”
From the H
OME menu press 4 (EDIT), 0 (EDIT LOOP MOTION), and then press 4 (LOOP EDIT).
Key Format:
Escape
1
Go To
Device
2
Home
3
Search
4
Z-Before-Y
5
Backbend
6
Loop
Elevation
7
Y-Offset
8
Clamp
Mode
9
Home
Menu
A
Loop
Pull
0
Nudge-up
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
90
ADVANCED PROGRAMMING
Search
An elevation at which the operation can visually place the bond. When the machine is in Half-Auto mode
or any key is held in Full-Auto mode, the bonder stops here at S
EARCH to allow the operator to make any
final adjustments to the bond position. This position should be set far enough from the chip to avoid
contact at this elevation- yet it should be close enough to make visual bond targeting possible.
EDIT SEARCH for Bond #1: 2024 from Home
4=Key in 5=Up (0.42167”)
7=Prev bond 8=Suggest 9=Next bond
A=Prev menu 0=Down G=Next option
Using keys 7 and 9, the operator can scroll
through all of the bonds in a single wire. This
feature makes programming quick and easy.
EDIT SEARCH for Bond #2: 145 from Loop
4=Key in 5=Up (0.03021”)
7=Prev bond 8=Suggest 9=Next bond
A=Prev menu 0=Down G=Next option
Notice the Search elevation on bond 2 is
measured from the loop, not from Home as
with the first bond.
ϑ To call “Search”
From the H
OME menu press 4 (EDIT), 0 (EDIT LOOP MOTION), 4 (LOOP EDIT), and then
press 4 (SEARCH).
Key Format:
Escape
1
Go To
Device
2
Home
3
Key In
4
Up
5
6
Previous
Bond
7
Suggest
8
Next
Bond
9
Previous
Menu
A
Down
0
Next
Option
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
91
ADVANCED PROGRAMMING
Z-Before-Y
The number of motor steps the motor raises up off of the work, after first bond, before making any
movement in the Y direction. Typically this elevation is used prior to backbend to aid in creating proper
loop shape.
Z-BEFORE-Y before Bond #1: n/a
5=Info
9=Next bond
A=Prev option G=Next option
Notice there is no Z-Before-Y setting available
before the first bond. This motion takes place
directly after the first bond.
Z-BEFORE-Y before Bond #2: 50 steps
4=Key in 5=Up (0.01042”)
7=Prev bond 8=Suggest 9=Next bond
A=Prev option 0=Down G=Next option
Too few motor steps in this setting can cause
the wire to be pulled off of the work if the
operator is also using the backbend feature.
ϑ To call “Z-Before-Y”
From the H
OME menu press 4 (EDIT), 0 (EDIT LOOP MOTION), 4 (LOOP EDIT), and then
press 5 (Z-B
EFORE-Y).
Key Format:
Escape
1
Go To
Device
2
Home
3
Key In
4
Up
5
6
Previous
Bond
7
Suggest
8
Next
Bond
9
Previous
Option
A
Down
0
Next
Option
G
