WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
68
ADVANCED PROGRAMMING
Device Edit Menu
From this menu option the operator can create new devices, copy device properties to another device for
modification, or simply select a device to be used. There can be as many as thirty devices programmed
on the 454647E.
DEVICE EDIT MENU
Edit Device 20 of 30:
4=Erase device 6=Copy device
7=Prev device 8=Device 1 9=Next device
A=Prev option G=Type edit
Key “4” will erase the device data.
Key “7” or “9” will step the operator through the devices.
Key “8” will return the operator to Device 1.
To Call “Device Edit”
From the H
OME menu press 4 (EDIT), and then press 7 (DEVICE EDIT)
Key Format:
Previous
Menu
1
Go To
Device/Type
2
Home
3
Erase
device
4
5
Copy device
6
Previous
Device
7
Device 1
8
Next device
9
Previous
Menu
A
0
Type Edit
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
69
ADVANCED PROGRAMMING
Erase Device
This option will allow the operator to erase all data from the selected device.
ERASE DEVICE
ERASE ALL DATA from Device 2:
Are you sure?
A=No
(This device has 3 types.) G=Yes
To call “Erase Device”
From the H
OME menu press 4 (EDIT), 7 (DEVICE EDIT) and then press 4 (ERASE DEVICE)
Key Format:
Previous
Menu
1
2
Home
3
4
5
6
7
8
9
Previous
Menu
A
0
Erase all
data from this
device G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
70
ADVANCED PROGRAMMING
Copy Device
This option will allow the operator to copy a device to another location for modification of a new device or
package with similar properties.
COPY DEVICE
COPY DEVICE 5 of 30 to Device: 30
5=Next destination
7=Prev source 9=Next source
A=Prev menu 0=Prev destination G=OK
Key “5” can advance one past the last device #, which
is also the default. Key “G” creates the copy, and goes
to the Edit Device Menu.
Key“1” or “A” = Device Edit Menu
To Call “Copy Device”
From the H
OME menu press 4 (EDIT), 7 (DEVICE EDIT) and then press 6 (COPY DEVICE)
Key Format:
Previous
Menu
1
Go To
Device/Type
2
Home
3
4
Next device
5
6
7
8
9
Previous
Menu
A
Previous
Device
0
OK
G
