4 Installation of SIPLACE Pro and possible Setup Types Installation Manual Edition 04/2015 SIPLACE Pro 12.1 33 Ste p 3 The "Configuration of SIPLACE Pr o Server" dial og box specifies unde r which Windows user …

Installation Manual 4 Installation of SIPLACE Pro and possible Setup Types

SIPLACE Pro 12.1 Edition 04/2015

Step 2

In the "Select languages" dialog box, select the languages you want to install to make them avail-

able for the applications. In addition, select which language should be active first.

You can switch the active language subsequently in SIPLACE Pro Desk and Line Control to any

other language installed.

Fig. 4.3 - 3 "Select Languages" dialog box

 Select the check box of the language with which the installed applications like SIPLACE Pro

Desk should start first.

 Click Next.

Note

Chinese (simplified.), English (US) and German are always installed. You cannot de-se-

lect either language. Additional languages are listed only if the language pack for this ver-

sion of SIPLACE Pro has been installed.

4 Installation of SIPLACE Pro and possible Setup Types Installation Manual

Edition 04/2015 SIPLACE Pro 12.1

Step 3

The "Configuration of SIPLACE Pro Server" dialog box specifies under which Windows user ac-

count the server component of SIPLACE Pro should run. The current domain appears as the de-

fault value in the account text box. This means it is usually sufficient just to add the account name

and the password. However, if this account is local, be sure to change the domain specification

appropriately.

Fig. 4.3 - 4 "Configuration of SIPLACE Pro" dialog box

 Enter the Account and Password for the Windows user in the dialog box.

 For new installations and upgrades, the option Access rights is deactivated by default. This

means there is no restriction of access rights on stored objects. We recommend you leave

this deactivated until you have created Users, Groups and set Privileges & Permissions in

SIPLACE Pro Desk. After having done that you may activate the option "Access Rights" by

modifying the option "Security On/Off" in the dialog "Settings" of SIPLACE Pro Desk.

 Click Next.

After SIPLACE Pro has successfully checked the user account and its administrator rights, the

SQL Server window opens.

Note

Make sure that the properties for the user account are set to "Password never expires".

Otherwise, as soon as the password has expired, the system will not be operable until

the COM+ package SIPLACE Pro has been reconfigured. This can be done using the

script COM+ServerAdmin.vbs, which is located in the Start Menu (Start -->Programs --

> SIPLACE Pro-->Administration --> COM+Server Administration). For more details

please contact your system administrator.

Installation Manual 4 Installation of SIPLACE Pro and possible Setup Types

SIPLACE Pro 12.1 Edition 04/2015

Step 4

In the "Select SQL-Server" dialog box you enter the information required to connect to the SQL

Server and database.

In case a SIPLACE Pro database already exists, the integrity of the database will be checked now.

If the check results in error messages, these messages will be displayed and the setup cannot

continue with this database. Only after selecting another database by choosing another SQL

server instance or after restoring the database in an error-free state setup can continue.

Fig. 4.3 - 5 "Select SQL-Server" dialog box - in case a database exists

 Enter the "Password for the SQL Server user "sa", i.e. the SQL server system administra-

tor.

 Choose your SQL Server Instance from the drop-down menu.

 Click Next

Note

If you installed the database using Support Media and did not configure a custom pass-

word, the password for the sa user will be the SIPLACE service default password. In this

case you don't have to enter the password for the account in this step - SIPLACE Pro

Setup will try to use the default password for connection to the database.
